231
5. Wait a while to allow all oil to drain out of gearbox.
6. Install drain plug and tighten to specification.
ttiigghhtteenniinngg ttoorrqquuee
Gearbox drain plug 6 ± 1 Nm (53 ± 9 lbf-in)
CChhaaiinnccaassee FFiilllliinngg PPrroocceedduurree
1. Open the RH side panel. Refer to
Equipment
.
2. Remove the check plug.
MAINTENANCE PROCEDURES
To Next Page
