This symbol informs you of additional references (data
sheets, Manuals, etc.) associated with the given subject.
Illustrations
The illustrations in this Manual are merely sketches and show
typical arrangements. They may not represent full detail or the
exact shape of the parts but should outline the same or similar
function. Therefore deriving dimensions or other details from il-
lustrations is not permitted.
TYPICAL indicates a general view which may not represent ex-
act details..
NOTE
The Illustrations in this Manual are stored in a graphic data
base system and are provided with a consecutive irrelevant
number.
This number (e.g. AE 5iS001) is of no significance for the
content.
