20
TTYYPPIICCAALL,, WWIITTHH BBRRAAKKEESS
1. Locking pin
2. Coupler-locking mechanism in locked
position
NNOOTTEE::
At this point the tow vehicle and the
trailer should be level.
9. Attach the tongue safety cables in
a crisscross pattern as shown.
NNOOTTIICCEE
TToo aavvooiidd ddaammaaggiinngg wwiirriinngg hhaarr--
nneessss,, eennssuurree tthhee hhaarrnneessss iiss nnoott
ppaasssseedd bbeettwweeeenn tthhee ttoonngguuee ssaaffeettyy
ccaabblleess..
1. LH tongue safety cable attached to the RH
side of hitch
2. RH tongue safety cable attached to the LH
side of hitch
10.Connect the trailer connector.
NNOOTTEE:: On brake-equipped trailers,
the electrical connector is a 5 pin type.
Adaptors to 4 pin type connector may
be available at your local auto parts
stores.
11.Ensure the back-up lock pin is not
installed before taking the road.
1. Back-up lock pin
WWAARRNNIINNGG
TThhee bbaacckk--uupp lloocckk ppiinn wwiillll pprreevveenntt
tthhee ttrraaiilleerr bbrraakkee ttoo aaccttiivvaattee wwhheenn
nneeeeddeedd.. TThhiiss mmaayy lleeaadd ttoo aa lloossss ooff
ccoonnttrrooll,, ccaauussiinngg iinnjjuurriieess oorr ddeeaatthh..
BEFORE GETTING UNDERWAY
