161
TTYYPPIICCAALL
Use this lever to select gears. The gearbox has two forward gears and
a neutral.
Shifting from one position to another is possible at speeds lower than
30 km/h (19 MPH)
CCAAUUTTIIOONN
SShhiiffttiinngg aatt aa ssppeeeedd ffaasstteerr tthhaann 3300 kkmm//hh ((1199 MMPPHH)) mmaayy ccaauussee
sseerriioouuss ddaammaaggee ttoo tthhee ggeeaarrbbooxx..
NNeeuuttrraall
The neutral position disengages the gearbox forward gears.
NNOOTTEE:: The reverse gear still can be activated.
HHiigghh RRaannggee ((FFoorrwwaarrdd))
This position selects the high speed range of the gearbox. It is the nor-
mal driving speed range. It allows the vehicle to reach its maximum
speed.
LLooww RRaannggee ((FFoorrwwaarrdd))
This position selects the low speed range of the gearbox. It allows the
vehicle to move slowly with maximum torque.
SECONDARY CONTROLS
