BSTA 180 – 500 BBV 190/85
BBV 190/85H
8
7. Should the tappet pins not be free, loosen up the pin screws until
both pins are free. Restart at point 6 again.
8. Turn the first tappet pin screw 12331.00.0.00 clockwise until the
tappet pin lays starts to move the dial gauge (indicator).
Afterwards turn the screw further to give 0.01mm tension on the
rocker arm.
9. Counter the tappet pin screw by means of the hexagonal nut
M10x0,8d.
10. Repeat the same procedure at the second tappet pin.
11. Check the pilot release function with two shims of 0,02mm
thickness and 500mm length.
