8 VERTEX 70v User Manual
3
INSTALLATION
Delivery Scope
For installing the vacuum pump, the following items are included:
• Vacuum pump (including the user manual)
• Noise reduction hood
• Vibration absorber
• 2x flexible metal hoses
• 4x hose clamps
• 4x sealing rings
Optional Components
Depending on the ordered spectrometer configuration, the delivery scope can also
include following optional components:
• Optional spectrometer components (e.g. optional detectors) and/or accessories
• Optional OPUS software packages (e.g OPUS/STEP) including the corresponding
manuals
Inspecting the Packaging
After the receipt of the spectrometer, inspect the packaging for damages. If there are
any signs of damage, contact your local shipping representative before opening the
shipping box.
Warning: Do not put a spectrometer into operation that shows signs of
damage. Failure to do so may result in severe personal injuries
and/or property damage.
Transportation
Due to its weight (about 105kg), VERTEX 70v has to be carried by at least four persons
using the supplied transport handles. For transportation purposes, attach these handles
properly to the right and left spectrometer side as shown in figure 1 using 12 screws
(M5 x 16). Tighten the screws using a hex kex (size 4mm). After having transported the
instrument to the desired place, you can remove the transport handles again. Alterna-
tively, you can transport the instrument with a fork lifter.
Warning: Due to the high instrument weight, improper transportation can
lead to personal injuries and/or spectrometer damage.
