BRUSTOR B150XL - Page 4

V01 - 2018B-150 (XL) Mounting instructions
1.a STAND ALONE
SINGLE
COUPLE
Pole support
Pole support
Ground Anchor
Ground Anchor
Floorplate 20x20
Floorplate 20x20
› Place the supports as indicated on the following drawings.
W
L
W - 3/8”
L - 1/4” L - 1-3/4”
L - 1-3/4”
W - 3-1/2” W - 1-5/8”
W - 1-5/8”
W - 3-1/2”
W - 3-1/2”
W - 3-1/2”
L - 3-1/2” L - 3-1/2” L - 3/8”
=
=
W
L
W
L
=
=
=
=
L
W
L
W
W
L
=
=
=
=
1/4”.
