ASSEMBLY STEP 3
ASSEMBLY STEP 3 INSTRUCTIONS
- 10 -
1. Fix smith machine holder (23) to the bottom frame plate (18) with M10*25 hexagon bolt
(27), Ø10 flat washer (6), and M10 lock nut (5). NOTE: M10*25 hexagon bolt (27) only
goes through one bottom frame plate (18).
2. Fix the bottom frame plate (18), jammer foot plate fixing bracket right (29) and the
jammer foot plate fixing bracket left (31) to the main frame with M10*80 hexagon bolt (30),
Ø10 flat washer (6), and M10 lock nut (5).
3. Install the pulley slider right (24) and pulley slider left (25) on the right (20) and left (32)
stainless steel front posts.
4. Install upright post (19), stainless steel front post right (20) and left (32) in middle of
bottom frame plate (18) with M10*75 hexagon bolt (4), Ø10 flat washer (6), M10 lock nut
(5).
5. Install upper frame plate (21), fixing plate (22) and upper decorative plate (28) on the
outside of upper side connection frame left (9).
