Brute Force UX1 - Page 10

ASSEMBLY STEP 3
- 9 -
No. Description Notes Qty
4
5
6
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Hexagon bolt
Lock nut
Flat washer
Bottom plate
Upright post
Stainless steel front post right
Upper frame plate
Fixed plate
Smith machine holder
Pulley slider right
Pulley slider left
Hexagon bolt
Hexagon bolt
Upper decorative plate
Jammer foot plate fixing bracket right
Hexagon bolt
Jammer foot plate fixing bracket left
Stainless steel front post left
NOTE: (27) only goes
through one plate (18)
to secure smith machine
holder (23).
M10*75
M10
Ø10
T5
50*50*2
50*50*1.5
T5
T5
-
-
-
M10*70
M10*25
T2
T4
M10*80
T4
50*50*1.5
18
30
60
4
2
1
2
2
1
1
1
4
2
2
1
6
1
1
6
28
21
26
4
26
4
30
4
30
30
4
4
18
19
20
19
32
25
24
22
29
6
5
31
23
18
22
26
26
4
4
4
30
27
4
