ASSEMBLY STEP 8
ASSEMBLY STEP 8 INSTRUCTIONS
- 20 -
1. Install the upper left/lower right triangle trim board (86) and upper right/lower left
triangle trim board (88) to the main frame with M8*20 hexagon bolt (87) and Ø8 flat
washer (41).
2. Install the shield right (82), shield rubber seal (85) and shield left (89) to the main frame
with M6*16 hexagon bolt (83) and Ø6 flat washer (84).
3. Attach all weight plate storage rod (80) to main frame with M8*16 hexagon bolt (40) and
Ø8 flat washer (41)
4. Spring collars (81) can be stored on weight plate storage rod (80).
5. Screw in storage hooks (90) on the main frame.
To Next Page
