Brute Force UX1 - Page 20

ASSEMBLY STEP 8
- 19 -
No. Description Notes Qty
40
41
80
81
82
83
84
85
86
87
88
89
90
Hexagon bolt
Flat washer
Weight plate storage
Spring collar
Shield right
Hexagon bolt
Flat washer
Shield rubber seal
Upper left/lower right triangle trim board
Hexagon bolt
Upper right/lower left triangle trim board
Shield left
Storage hook
M8*16
Ø8
-
Ø50
-
M6*16
Ø6
32*1956
-
M8*20
-
-
-
12
20
6
6
1
10
10
1
2
8
2
1
10
86
88
86
88
81
80
40
41
90
89
82
85
83
84
83
84
83
84
41
87
