ASSEMBLY STEP 10
ASSEMBLY STEP 10 INSTRUCTIONS
- 24 -
1. Leg press plate (100) fixes to the smith machine with Ø10*85 T-shape locking pin (101).
2. Use Ø10*85 T-shape locking pin (101) to secure jammer arm foot plate (102) to the main
frame.
