ASSEMBLY STEP 11
- 25 -
No. Description Notes Qty
61
67
68
81
101
103
104
105
106
107
108
109
120
Aluminium cover
Hexagon bolt
Spring washer
Spring collar
T-shape locking pin
Jammer arm fixing bracket right
Jammer arm right
Jammer handle
Jammer arm stopper bracket right
Jammer arm front rod
Jammer arm fixing bracket left
Jammer arm left
Jammer arm stopper bracket left
Ø50*Ø19*Ø11
M10*20
Ø10
Ø50
Ø10*85
-
-
-
-
-
-
-
-
2
2
2
2
2
1
1
2
1
1
1
1
1
67
68
61
108
109
105
120
104
101 81
107
109
106
103
