36
CONDENSER ONLY RATINGS* CONTINUED
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
113A*A042 --- C
30
( --- 1.11)
TCG 38.00 36.00 33.90 31.90 29.70 27.60 25.30 22.90
SDT 73.20 82.30 91.40 100.60 109.80 119.10 128.40 137.70
KW 1.95 2.20 2.48 2.80 3.14 3.53 3.95 4.41
35
(1.67)
TCG 41.90 39.70 37.40 35.10 32.80 30.50 28.00 25.50
SDT 74.80 83.70 92.80 101.90 111.00 120.20 129.40 138.60
KW 1.97 2.22 2.50 2.81 3.16 3.54 3.97 4.43
40
(4.44)
TCG 46.00 43.60 41.10 38.70 36.20 33.60 30.90 28.10
SDT 76.40 85.20 94.20 103.20 112.20 121.30 130.40 139.50
KW 1.98 2.23 2.52 2.83 3.18 3.56 3.98 4.44
45
(7.22)
TCG 50.30 47.70 45.10 42.40 39.60 36.80 33.90 30.90
SDT 78.10 86.90 95.70 104.60 113.50 122.50 131.40 140.40
KW 2.01 2.26 2.54 2.85 3.19 3.58 4.00 4.45
50
(10.0)
TCG 54.90 52.10 49.20 46.20 43.20 40.20 37.00 33.60
SDT 80.00 88.60 97.20 106.00 114.80 123.70 132.50 141.30
KW 2.03 2.28 2.56 2.87 3.21 3.60 4.01 4.47
55
(12.78)
TCG 59.70 56.60 53.40 50.20 46.90 43.50 40.10 36.40
SDT 81.90 90.30 98.90 107.50 116.20 124.90 133.60 142.20
KW 2.06 2.30 2.58 2.89 3.23 3.62 4.03 4.48
113A*A048 --- E
30
( --- 1.11)
TCG 41.10 38.90 36.70 34.40 32.10 29.70 27.20 24.50
SDT 73.80 83.00 92.30 101.60 111.00 120.40 129.70 139.10
KW 2.19 2.46 2.76 3.10 3.47 3.87 4.30 4.76
35
(1.67)
TCG 45.20 42.80 40.50 38.00 35.50 32.90 30.20 27.40
SDT 75.30 84.40 93.70 102.90 112.20 121.50 130.80 140.00
KW 2.22 2.49 2.79 3.13 3.50 3.90 4.34 4.81
40
(4.44)
TCG 49.60 47.10 44.50 41.90 39.20 36.40 33.50 30.40
SDT 76.90 86.00 95.10 104.30 113.40 122.60 131.80 141.00
KW 2.24 2.51 2.82 3.15 3.53 3.93 4.38 4.85
45
(7.22)
TCG 54.30 51.60 48.80 46.00 43.10 40.10 36.90 33.60
SDT 78.50 87.50 96.60 105.70 114.70 123.80 132.90 142.00
KW 2.27 2.54 2.85 3.19 3.56 3.97 4.41 4.89
50
(10.0)
TCG 59.30 56.40 53.40 50.30 47.10 43.90 40.50 36.90
SDT 80.20 89.20 98.10 107.10 116.10 125.10 134.10 143.00
KW 2.30 2.58 2.88 3.22 3.59 4.00 4.45 4.92
55
(12.78)
TCG 64.60 61.40 58.10 54.80 51.40 47.90 44.20 40.30
SDT 82.10 91.00 99.80 108.70 117.50 126.40 135.20 144.00
KW 2.34 2.61 2.92 3.25 3.63 4.04 4.48 4.96
113A*A060 --- F
30
( --- 1.11)
TCG 57.30 54.20 51.10 47.90 44.60 41.30 37.80 34.10
SDT 77.40 86.30 95.20 104.30 113.30 122.30 131.30 140.30
KW 2.71 3.05 3.43 3.86 4.33 4.84 5.40 5.99
35
(1.67)
TCG 62.90 59.50 56.10 52.60 49.00 45.40 41.60 37.50
SDT 79.30 88.00 96.90 105.80 114.70 123.70 132.60 141.40
KW 2.76 3.11 3.49 3.92 4.39 4.90 5.46 6.06
40
(4.44)
TCG 68.70 65.00 61.30 57.50 53.60 49.60 45.50 41.00
SDT 81.30 89.90 98.70 107.50 116.20 125.00 133.80 142.50
KW 2.83 3.17 3.56 3.98 4.45 4.96 5.52 6.12
45
(7.22)
TCG 74.80 70.80 66.70 62.60 58.30 54.00 49.40 44.60
SDT 83.40 91.90 100.50 109.20 117.80 126.50 135.10 143.60
KW 2.90 3.24 3.62 4.05 4.52 5.03 5.58 6.18
50
(10.0)
TCG 81.20 76.80 72.30 67.80 63.10 58.40 53.40 48.10
SDT 85.60 94.00 102.50 111.00 119.50 128.00 136.40 144.70
KW 2.97 3.32 3.70 4.12 4.59 5.10 5.65 6.24
55
(12.78)
TCG 87.80 83.00 78.10 73.10 68.10 62.90 57.50 51.70
SDT 88.00 96.20 104.40 112.80 121.10 129.50 137.70 145.80
KW 3.05 3.40 3.78 4.20 4.66 5.17 5.72 6.30
* ARI listing applies on l y to systems shown in Combination Ratings table.
KW --- Outdoor Unit Kilowatts Only.
SDT --- Saturated Temperature Leaving Compressor (° F/° C)
SST --- Saturated Temperature Entering Compressor (° F/° C)
TCG --- Gross Cooling Capacity (1000 Btuh)
113A
