Bryant 113A User Manual

7
ELECTRICAL DATA
UNIT
S I Z E ---
VOLTAGE,
SERIES
V/PH
OPER VOLTS* COMPR FAN
MCA
MIN WIRE
SIZE{
MIN WIRE
SIZE{
MAX
LENGTH
(FT)}
MAX
LENGTH
(FT)}
MAX
FUSE**
or CKT
BRK
AMPS
MAX MIN LRA RLA FLA 60° C 75° C 60° C 75° C
018---D
208/230/1 253 197
48.0 9.0 0.5 11.8 14 14 66 (20.1) 63 (21.0) 15
024---D 58.3 13.5 0.75 17.6 14 14 44 ( 13.4) 42 (12.8) 25
030---E 64.0 12.8 1.4 16.8 14 14 46 (14.0) 44 (13.4) 25
036---E 77.0 14.1 1.4 20.5 12 12 61 (18.6) 58 (17.7) 30
042---C 112.0 17.9 1.1 23.5 12 12 53 (16.2) 51 (15.5) 40
048---E 109.0 19.9 1.4 26.2 10 10 76 (23.2) 72 (22.2) 40
060---F 134.0 26.4 1.2 34.2 8 10 62 (18.9) 55 ( 16.8) 50
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{ If wire is applied at ambient greater than 30_C(86_F), consult table 310---16 of the NEC (ANSI/NFPA 70). Th e ampacity of non ---metallic---sheathed cable
(NM), trade name ROMEX, shall be that of 60_C (140_F) conditions, per the NEC (ANSI/NFPA 70) Article 336---26. If othe r than uncoated (no ---plated), 60 or
75_C (140 or 167_F) insulation, copper wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of the
NEC (ANSI/NFPA 70).
} Length shown is as measured one way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i m e --- D e l a y f u s e .
FLA --- F u l l L o a d A m p s
LRA --- L o c k e d R o t o r A m p s
MCA --- Minimum Circuit Amps
RLA ---RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
A--WEIGHTED SOUND POWER (dBA)
U N I T S I Z E ---
SERIES
STANDARD
RATING
(dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA, without tone adjustment)
125 250 500 1000 2000 4000 8000
018---D 72 53.5 59.5 63.5 67.0 63.5 59.0 52.5
024---D 76 55.0 61.5 67.0 71.5 69.0 61.0 55.0
030---E 74 55.0 63.5 68.5 68.5 65.5 61.0 54.0
036---E 75 59.5 63.0 68.5 70.0 65.5 61.5 53.5
042---C 78 57.5 65.0 71.0 73.0 70.5 67.5 62.5
048---E 80 58.5 67.5 73.5 75.0 70.5 67.5 64.5
060---F 78 59.0 67.5 71.5 73.5 69.0 66.0 63.5
NOTE: Tested in accordance with ARI Standard 270---95 (not listed in ARI).
A--WEIGHTED SOUND POWER WITH SOUND BLANKET (dBA)
U N I T S I Z E ---
SERIES
STANDARD
RATING
(dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA, without tone adjustment)
125 250 500 1000 2000 4000 8000
018---D 71 55.5 60.5 64.0 66.0 63.0 58.5 52.0
024---D 74 55.5 60.5 68.5 70.0 67.0 61.0 53.6
030---E 73 55.5 64.0 68.0 67.0 64.0 60.0 52.5
036---E 74 59.5 63.0 68.0 69.5 65.0 60.5 50.5
042---C 77 57.5 65.0 70.5 72.0 70.0 67.0 62.0
048---E 79 60.5 67.5 73.5 74.5 71.0 68.0 63.5
060---F 78 59.0 68.0 70.5 72.5 68.0 67.0 63.0
NOTE: Tested in accordance with ARI Standard 270---95 (not listed in ARI).
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE --- SERIES REQUIRED SUBCOOLING _F(_C)
018---D 8 ( 4.4)
024---D 13 (7.2)
030---E 16 (8.9)
036---E 14 (7.8)
042---C 10 ( 5.6)
048---E 15 (8.3)
060---F 11 (6.1)
113A
