Bryant 225B - Page 32

32
DETAILED COOLING CAPACITIES
#
CONTINUED
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Tot a l Sens‡ To t a l Sens‡ To t a l Sens‡ Tot a l Sens‡ To tal Sens‡ Total Sens‡
225BNA030****AOutdoor Section With FX4DNF031 Indoor Section
875
72 (22.2) 34.40 17.74 1.83 32.81 17.14 2.05 31.16 16.52 2.29 29.42 15.88 2.56 27.55 15.20 2.87 25.53 14.48 3.23 67 (19.4) 31.23 21.80 1.82 29.80 21.20 2.04 28.29 20.57 2.28 26.69 19.93 2.55 24.96 19.24 2.86 23.10 18.49 3.22
63 (17.2)† † 28.95 20.97 1.81 27.62 20.37 2.03 26.22 19.74 2.27 24.73 19.09 2.54 23.11 18.39 2.86 21.35 17.64 3.22
62 (16.7) 28.38 25.74 1.81 27.09 25.12 2.03 25.75 24.46 2.26 24.33 23.73 2.54 22.91 22.91 2.86 21.51 21.51 3.22 57 (13.9) 27.40 27.40 1.81 26.39 26.39 2.02 25.32 25.32 2.26 24.15 24.15 2.54 22.88 22.88 2.86 21.48 21.48 3.22
1000
72 (22.2) 35.08 18.63 1.86 33.43 18.02 2.08 31.71 17.39 2.32 29.89 16.74 2.59 27.95 16.05 2.90 25.86 15.32 3.25 67 (19.4) 31.88 23.23 1.85 30.37 22.61 2.06 28.80 21.98 2.30 27.13 21.31 2.58 25.35 20.60 2.89 23.43 19.84 3.24
63 (17.2)† † 29.57 22.30 1.84 28.18 21.68 2.05 26.71 21.05 2.29 25.16 20.38 2.57 23.49 19.66 2.88 21.67 18.88 3.24
62 (16.7) 29.06 27.61 1.84 27.73 26.92 2.05 26.39 26.39 2.29 25.13 25.13 2.57 23.77 23.77 2.88 22.28 22.28 3.24 57 (13.9) 28.58 28.58 1.84 27.49 27.49 2.05 26.34 26.34 2.29 25.10 25.10 2.57 23.74 23.74 2.88 22.26 22.26 3.24
1125
72 (22.2) 35.61 19.48 1.89 33.89 18.86 2.11 32.11 18.22 2.35 30.24 17.56 2.62 28.25 16.86 2.93 26.10 16.12 3.28 67 (19.4) 32.37 24.59 1.87 30.81 23.96 2.09 29.18 23.31 2.33 27.47 22.63 2.60 25.64 21.90 2.91 23.68 21.10 3.27
63 (17.2)† † 30.05 23.56 1.86 28.60 22.94 2.08 27.09 22.29 2.32 25.49 21.60 2.59 23.78 20.86 2.91 21.93 20.05 3.27
62 (16.7) 29.68 29.51 1.86 28.45 28.45 2.08 27.22 27.22 2.32 25.91 25.91 2.60 24.49 24.49 2.91 22.92 22.92 3.27 57 (13.9) 29.56 29.56 1.86 28.41 28.41 2.08 27.19 27.19 2.32 25.88 25.88 2.59 24.46 24.46 2.91 22.89 22.89 3.27
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*FX4DN(B,F)031 1.00 1.00
FB4CNF030 0.99 1.03 FB4CNF036 0.99 1.03
FE4AN(B,F)003 0.99 0.99 FE4AN(B,F)005 1.01 0.98
FE4ANF002 0.99 0.99 FF1ENP030 0.96 1.08 FF1ENP031 0.99 1.03 FF1ENP036 0.99 1.10 FF1ENP037 0.99 1.03
FV4BN(B,F)003 0.99 0.99 FV4BN(B,F)005 1.01 0.98
FV4BNF002 0.99 0.99
FV4CN(B,F)003 0.99 0.99 FV4CN(B,F)005 1.01 0.98
FV4CNF002 0.99 0.99
FX4CN(B,F)036 0.99 1.03
FX4CNF030 0.99 1.03
FX4DN(B,F)037 1.02 1.02
FY4ANF030 0.97 1.08 FY4ANF036 0.98 1.09 FY5BNF030 0.99 1.03 FY5BNF036 0.99 1.07
CAP**3014A** 0.98 1.09 CAP**3017A** 0.98 1.09 CAP**3614A** 0.98 1.09 CAP**3617A** 0.98 1.09 CAP**3619A** 0.98 1.09 CAP**3621A** 0.98 1.09
CNPF*3618A** 0.98 1.09
CNPH*3017A** 0.98 1.09 CNPH*3617A** 0.98 1.09
CNPV*3014A** 0.98 1.09 CNPV*3017A** 0.98 1.09 CNPV*3117A** 1.01 1.09 CNPV*3617A** 0.98 1.09 CNPV*3621A** 0.98 1.09
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPV*3717A** 1.01 1.10
CSPH*3012A** 0.98 1.09 CSPH*3612A** 0.98 1.09
CAP**3014A** 0.97 1.01 315(A,J)AV036070 CAP**3614A** 0.98 1.02 315(A,J)AV036070
CNPH*3017A** 0.98 1.02 315(A,J)AV036070 CNPH*3617A** 0.98 1.02 315(A,J)AV036070
CNPV*3014A** 0.97 1.01 315(A,J)AV036070
CSPH*3012A** 0.98 1.02 315(A,J)AV036070 CSPH*3612A** 0.98 1.02 315(A,J)AV036070
CAP**3017A** 0.98 0.98 315(A,J)AV048090 CAP**3617A** 0.98 0.98 315(A,J)AV048090
CNPH*3017A** 0.98 0.98 315(A,J)AV048090 CNPH*3617A** 0.98 0.98 315(A,J)AV048090
CNPV*3017A** 0.98 0.98 315(A,J)AV048090 CNPV*3117A** 1.00 1.00 315(A,J)AV048090 CNPV*3617A** 0.98 0.98 315(A,J)AV048090 CNPV*3717A** 1.01 1.01 315(A,J)AV048090
CSPH*3012A** 0.98 0.98 315(A,J)AV048090 CSPH*3612A** 0.98 0.98 315(A,J)AV048090
CAP**3621A** 0.98 0.98 315(A,J)AV060110
CNPH*3017A** 0.98 0.98 315(A,J)AV060110 CNPH*3617A** 0.98 0.98 315(A,J)AV060110
CNPV*3621A** 0.98 0.98 315(A,J)AV060110
CSPH*3012A** 0.98 0.98 315(A,J)AV060110 CSPH*3612A** 0.98 0.98 315(A,J)AV060110
CNPH*3017A** 0.98 0.98 315(A,J)AV066135 CNPH*3617A** 0.98 0.98 315(A,J)AV066135
CSPH*3012A** 0.98 0.98 315(A,J)AV066135 CSPH*3612A** 0.98 0.98 315(A,J)AV066135
CNPH*3017A** 0.98 0.98 315(A,J)AV066155 CNPH*3617A** 0.98 0.98 315(A,J)AV066155
CSPH*3012A** 0.98 0.98 315(A,J)AV066155 CSPH*3612A** 0.98 0.98 315(A,J)AV066155
CAP**3619A** 0.98 1.02 359BAV036040 CAP**3619A** 0.98 1.02 359BAV036040
CNPH*3017A** 0.98 1.06 359BAV036040
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPH*3117A** 1.00 1.02 359BAV036040 CNPH*3617A** 0.98 1.06 359BAV036040
CSPH*3012A** 0.98 1.06 359BAV036040 CSPH*3612A** 0.98 1.02 359BAV036040
CAP**3619A** 0.98 1.02 359BAV036060 CAP**3619A** 0.98 1.02 359BAV036060
CNPH*3017A** 0.99 1.03 359BAV036060 CNPH*3117A** 1.01 1.03 359BAV036060 CNPH*3617A** 0.99 1.03 359BAV036060
CSPH*3012A** 0.99 1.03 359BAV036060 CSPH*3612A** 0.99 1.03 359BAV036060
CAP**3017A** 0.99 0.99 353(A,B)AV036060 CAP**3617A** 0.99 0.99 353(A,B)AV036060
CNPH*3017A** 0.99 0.99 353(A,B)AV036060 CNPH*3617A** 0.99 0.99 353(A,B)AV036060
CNPV*3017A** 0.99 0.99 353(A,B)AV036060 CNPV*3117A** 1.01 1.01 353(A,B)AV036060 CNPV*3617A** 0.99 0.99 353(A,B)AV036060 CNPV*3717A** 1.01 1.01 353(A,B)AV036060
CSPH*3012A** 0.99 0.99 353(A,B)AV036060 CSPH*3612A** 0.99 0.99 353(A,B)AV036060
CAP**3017A** 0.99 0.99 353(A,B)AV036080 CAP**3617A** 0.99 0.99 353(A,B)AV036080
CNPH*3017A** 0.99 0.99 353(A,B)AV036080 CNPH*3617A** 0.99 0.99 353(A,B)AV036080
CNPV*3017A** 0.99 0.99 353(A,B)AV036080 CNPV*3117A** 1.01 1.01 353(A,B)AV036080 CNPV*3617A** 0.99 0.99 353(A,B)AV036080 CNPV*3717A** 1.03 1.03 353(A,B)AV036080
CSPH*3012A** 0.99 0.99 353(A,B)AV036080 CSPH*3612A** 0.99 0.99 353(A,B)AV036080
CAP**3017A** 0.99 0.99 353(A,B)AV048080 CAP**3617A** 0.99 0.99 353(A,B)AV048080
CNPH*3017A** 0.99 1.01 353(A,B)AV048080 CNPH*3617A** 0.99 1.01 353(A,B)AV048080
CNPV*3017A** 0.99 1.01 353(A,B)AV048080 CNPV*3117A** 1.02 1.02 353(A,B)AV048080
225B
