Bryant 225B - Page 38

38
DETAILED COOLING CAPACITIES
#
CONTINUED
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Tot a l Sens‡ To t a l Sens‡ To t a l Sens‡ Tot a l Sens‡ To tal Sens‡ Total Sens‡
225BNA048****AOutdoor Section With FX4DNF049 Indoor Section
1400
72 (22.2) 57.26 29.51 2.88 54.23 28.34 3.32 51.16 27.19 3.75 48.02 26.02 4.19 44.73 24.81 4.65 41.29 23.57 5.16 67 (19.4) 52.18 36.28 2.92 49.48 35.14 3.33 46.73 33.99 3.74 43.90 32.83 4.17 40.93 31.62 4.62 37.80 30.36 5.14
63 (17.2)† † 48.48 34.97 2.94 46.01 33.84 3.34 43.48 32.71 3.73 40.88 31.55 4.15 38.14 30.36 4.60 35.25 29.10 5.11
62 (16.7) 47.52 42.88 2.95 45.12 41.72 3.34 42.69 40.54 3.73 40.19 39.27 4.14 37.70 37.70 4.60 35.35 35.35 5.12 57 (13.9) 45.66 45.66 2.96 43.79 43.79 3.34 41.86 41.86 3.72 39.82 39.82 4.14 37.65 37.65 4.60 35.30 35.30 5.12
1600
72 (22.2) 58.35 30.94 2.92 55.18 29.75 3.36 51.96 28.57 3.80 48.68 27.37 4.24 45.27 26.15 4.71 41.70 24.88 5.22 67 (19.4) 53.25 38.62 2.96 50.38 37.44 3.38 47.50 36.26 3.79 44.54 35.07 4.22 41.45 33.83 4.68 38.22 32.53 5.19
63 (17.2)† † 49.51 37.15 2.98 46.89 35.98 3.38 44.25 34.83 3.78 41.52 33.64 4.20 38.69 32.41 4.66 35.70 31.12 5.17
62 (16.7) 48.61 45.99 2.99 46.11 44.72 3.38 43.64 43.39 3.78 41.34 41.34 4.20 39.01 39.01 4.66 36.50 36.50 5.18 57 (13.9) 47.59 47.59 2.99 45.57 45.57 3.38 43.48 43.48 3.78 41.28 41.28 4.20 38.96 38.96 4.66 36.46 36.46 5.18
1800
72 (22.2) 59.17 32.29 2.96 55.88 31.08 3.41 52.54 29.88 3.84 49.16 28.67 4.29 45.65 27.43 4.76 41.98 26.15 5.27 67 (19.4) 54.02 40.84 3.00 51.05 39.64 3.42 48.06 38.43 3.84 45.00 37.20 4.27 41.84 35.93 4.73 38.52 34.58 5.24
63 (17.2)† † 50.28 39.22 3.03 47.57 38.03 3.43 44.82 36.83 3.83 42.01 35.62 4.25 39.10 34.35 4.71 36.04 33.00 5.22
62 (16.7) 49.55 48.76 3.03 47.11 47.11 3.43 44.87 44.87 3.83 42.54 42.54 4.26 40.07 40.07 4.72 37.40 37.40 5.23 57 (13.9) 49.21 49.21 3.03 47.04 47.04 3.43 44.81 44.81 3.83 42.49 42.49 4.26 40.03 40.03 4.72 37.36 37.36 5.23
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*FX4DN(B,F)049 1.00 1.00
FB4CNF048 0.97 1.05 FB4CNF060 0.99 1.03
FE4AN(B,F)005 0.98 0.98
FE4ANB006 0.99 0.99
FV4BN(B,F)005 0.98 0.98
FV4BNB006 0.99 0.99
FV4CN(B,F)005 0.98 0.98
FV4CNB006 0.99 0.99
FX4CN(B,F)048 0.99 1.03 FX4CN(B,F)060 1.00 1.00 FX4DN(B,F)061 1.01 1.01
FY4ANB060 0.99 1.08
FY4ANF048 0.97 1.08
FY5BNB060 1.00 1.09
FY5BNF048 0.98 1.02
CAP**4817A** 0.95 1.03 CAP**4821A** 0.96 1.04 CAP**4823A** 0.96 1.04 CAP**4824A** 0.96 1.04 CAP**6021A** 0.98 1.06 CAP**6024A** 0.98 1.06 CAP**6025A** 0.98 1.06
CNPF*4818A** 0.94 1.02
CNPH*4821A** 0.96 1.04 CNPH*6024A** 0.98 1.06 CNPH*6124A** 0.99 1.08
CNPV*4821A** 0.96 1.04 CNPV*4824A** 0.96 1.04 CNPV*6024A** 0.98 1.06 CNPV*6124A** 0.99 1.08
CSPH*4812A** 0.96 1.04 CSPH*6012A** 0.98 1.06
CAP**4817A** 0.96 1.04 315(A,J)AV048090
CNPH*4821A** 0.95 0.99 315(A,J)AV048090 CNPH*6024A** 0.97 1.01 315(A,J)AV048090 CNPH*6124A** 0.97 1.01 315(A,J)AV048090
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CSPH*4812A** 0.96 1.00 315(A,J)AV048090 CSPH*6012A** 0.98 1.02 315(A,J)AV048090
CAP**4821A** 0.95 1.03 315(A,J)AV060110 CAP**6021A** 0.97 1.01 315(A,J)AV060110
CNPH*4821A** 0.96 1.00 315(A,J)AV060110 CNPH*6024A** 0.97 1.01 315(A,J)AV060110 CNPH*6124A** 0.98 1.02 315(A,J)AV060110
CNPV*4821A** 0.96 1.00 315(A,J)AV060110 CNPV*6124A** 0.99 0.99 315(A,J)AV060110
CSPH*4812A** 0.96 1.00 315(A,J)AV060110 CSPH*6012A** 0.98 1.02 315(A,J)AV060110
CAP**4824A** 0.96 1.00 315(A,J)AV066135 CAP**6024A** 0.97 1.01 315(A,J)AV066135
CNPH*4821A** 0.96 1.00 315(A,J)AV066135 CNPH*6024A** 0.97 0.97 315(A,J)AV066135 CNPH*6124A** 0.98 0.98 315(A,J)AV066135
CNPV*4824A** 0.96 1.00 315(A,J)AV066135 CNPV*6024A** 0.97 0.97 315(A,J)AV066135 CNPV*6124A** 0.99 0.99 315(A,J)AV066135
CSPH*4812A** 0.97 1.01 315(A,J)AV066135 CSPH*6012A** 0.98 0.98 315(A,J)AV066135
CAP**4824A** 0.96 1.00 315(A,J)AV066155 CAP**6024A** 0.98 0.98 315(A,J)AV066155
CNPH*4821A** 0.96 1.00 315(A,J)AV066155 CNPH*6024A** 0.98 0.98 315(A,J)AV066155 CNPH*6124A** 0.98 0.98 315(A,J)AV066155
CNPV*4824A** 0.96 1.00 315(A,J)AV066155 CNPV*6024A** 0.98 0.98 315(A,J)AV066155 CNPV*6124A** 0.99 0.99 315(A,J)AV066155
CSPH*4812A** 0.97 1.01 315(A,J)AV066155 CSPH*6012A** 0.98 0.98 315(A,J)AV066155
CAP**4823A** 0.96 1.04 359BAV060080
CNPH*4821A** 0.96 1.04 359BAV060080 CNPH*6024A** 0.99 1.03 359BAV060080 CNPH*6124A** 0.99 1.03 359BAV060080
CSPH*4812A** 0.96 1.04 359BAV060080 CSPH*6012A** 0.98 1.02 359BAV060080
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CAP**6025A** 0.98 1.02 359BAV060100
CNPH*4821A** 0.97 1.01 359BAV060100 CNPH*6024A** 0.98 1.02 359BAV060100 CNPH*6124A** 0.99 1.01 359BAV060100
CNPV*4824A** 0.97 1.01 359BAV060100 CNPV*6024A** 0.98 1.02 359BAV060100 CNPV*6124A** 1.00 1.02 359BAV060100
CSPH*4812A** 0.97 1.01 359BAV060100 CSPH*6012A** 0.97 1.01 359BAV060100
CAP**4817A** 0.96 1.04 353(A,B)AV048080
CNPH*4821A** 0.96 1.04 353(A,B)AV048080 CNPH*6024A** 0.98 1.02 353(A,B)AV048080 CNPH*6124A** 0.98 1.02 353(A,B)AV048080
CSPH*4812A** 0.97 1.05 353(A,B)AV048080 CSPH*6012A** 0.98 1.02 353(A,B)AV048080
CAP**4821A** 0.96 1.00 353(A,B)AV060100 CAP**6021A** 0.98 1.02 353(A,B)AV060100
CNPH*4821A** 0.96 1.00 353(A,B)AV060100 CNPH*6024A** 0.98 1.02 353(A,B)AV060100 CNPH*6124A** 0.98 1.02 353(A,B)AV060100
CNPV*4821A** 0.96 1.00 353(A,B)AV060100
CSPH*4812A** 0.97 1.01 353(A,B)AV060100 CSPH*6012A** 0.99 1.03 353(A,B)AV060100
CAP**4824A** 0.96 1.00 353(A,B)AV060120 CAP**6024A** 0.98 1.02 353(A,B)AV060120
CNPH*4821A** 0.97 1.01 353(A,B)AV060120 CNPH*6024A** 0.98 1.02 353(A,B)AV060120 CNPH*6124A** 0.99 0.99 353(A,B)AV060120
CNPV*4824A** 0.97 1.01 353(A,B)AV060120 CNPV*6024A** 0.98 1.02 353(A,B)AV060120 CNPV*6124A** 0.99 0.99 353(A,B)AV060120 CNPV*6124A** 1.01 1.01 353(A,B)AV060120
CSPH*4812A** 0.97 1.01 353(A,B)AV060120 CSPH*6012A** 0.99 0.99 353(A,B)AV060120
CAP**4821A** 0.94 1.02 355(A,C)AV060080 CAP**6021A** 0.96 1.00 355(A,C)AV060080
CNPH*4821A** 0.95 1.03 355(A,C)AV060080
225B
