40
DETAILED COOLING CAPACITIES
#
CONTINUED
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Capacity MBtuh†
Tot a l Sy s -
tem KW**
Tot a l Sens‡ To t a l Sens‡ To t a l Sens‡ Tot a l Sens‡ To tal Sens‡ Total Sens‡
225BNA060****AOutdoor Section With FX4DNF061 Indoor Section
1750
72 (22.2) 69.17 35.96 3.81 65.83 34.68 4.20 62.32 33.37 4.63 58.60 31.99 5.12 54.63 30.54 5.68 50.41 29.02 6.30
67 (19.4) 63.19 44.51 3.74 60.19 43.24 4.13 57.00 41.92 4.56 53.63 40.55 5.05 50.02 39.09 5.61 46.18 37.54 6.25
63 (17.2)† † 58.86 42.93 3.69 56.08 41.67 4.08 53.14 40.35 4.51 50.02 38.98 5.00 46.68 37.53 5.56 43.12 35.99 6.21
62 (16.7) 57.71 52.83 3.68 55.03 51.53 4.07 52.20 50.14 4.50 49.23 48.59 4.99 46.32 46.32 5.56 43.40 43.40 6.21
57 (13.9) 55.78 55.78 3.66 53.67 53.67 4.05 51.40 51.40 4.49 48.93 48.93 4.99 46.26 46.26 5.56 43.34 43.34 6.21
2000
72 (22.2) 70.36 37.71 3.89 66.90 36.42 4.28 63.21 35.07 4.71 59.35 33.67 5.20 55.24 32.20 5.75 50.87 30.66 6.38
67 (19.4) 64.35 47.38 3.82 61.20 46.09 4.21 57.88 44.75 4.64 54.36 43.33 5.13 50.63 41.84 5.69 46.66 40.25 6.32
63 (17.2)† † 59.99 45.61 3.77 57.09 44.32 4.15 54.01 42.98 4.59 50.76 41.57 5.08 47.31 40.08 5.64 43.61 38.48 6.28
62 (16.7) 58.97 56.64 3.76 56.19 55.19 4.15 53.39 53.39 4.58 50.73 50.73 5.08 47.86 47.86 5.65 44.74 44.74 6.30
57 (13.9) 58.06 58.06 3.75 55.76 55.76 4.14 53.31 53.31 4.58 50.67 50.67 5.08 47.80 47.80 5.65 44.69 44.69 6.29
2250
72 (22.2) 71.26 39.37 3.97 67.65 38.06 4.36 63.86 36.70 4.79 59.89 35.28 5.27 55.65 33.79 5.82 51.19 32.24 6.45
67 (19.4) 65.22 50.14 3.89 61.95 48.81 4.28 58.50 47.43 4.71 54.89 45.99 5.20 51.06 44.45 5.76 47.00 42.79 6.39
63 (17.2)† † 60.84 48.17 3.84 57.83 46.84 4.23 54.65 45.48 4.66 51.31 44.03 5.15 47.75 42.48 5.71 43.99 40.82 6.35
62 (16.7) 60.05 60.05 3.84 57.56 57.56 4.23 54.95 54.95 4.67 52.14 52.14 5.16 49.11 49.11 5.73 45.81 45.81 6.38
57 (13.9) 59.92 59.92 3.84 57.48 57.48 4.23 54.88 54.88 4.67 52.08 52.08 5.16 49.05 49.05 5.73 45.76 45.76 6.38
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*FX4DN(B,F)061 1.00 1.00
FB4CNF060 0.97 1.06
FE4ANB006 0.99 0.99
FV4BNB006 0.99 0.99
FV4CNB006 0.99 0.99
FX4CN(B,F)060 0.99 1.03
FY4ANB060 0.98 1.07
FY5BNB060 0.98 1.07
CAP**6021A** 0.97 1.06
CAP**6024A** 0.97 1.06
CAP**6025A** 0.97 1.06
CNPH*6024A** 0.97 1.06
CNPH*6124A** 0.98 1.07
CNPV*6024A** 0.97 1.06
CNPV*6124A** 0.99 1.08
CSPH*6012A** 0.97 1.06
CAP**6021A** 0.97 1.06 315(A,J)AV060110
CNPH*6024A** 0.97 1.06 315(A,J)AV060110
CNPH*6124A** 0.98 1.07 315(A,J)AV060110
CSPH*6012A** 0.98 1.07 315(A,J)AV060110
CAP**6024A** 0.97 1.01 315(A,J)AV066135
CNPH*6024A** 0.97 1.01 315(A,J)AV066135
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPH*6124A** 0.98 1.02 315(A,J)AV066135
CNPV*6024A** 0.97 1.01 315(A,J)AV066135
CNPV*6124A** 0.99 1.03 315(A,J)AV066135
CSPH*6012A** 0.98 1.02 315(A,J)AV066135
CAP**6024A** 0.98 1.02 315(A,J)AV066155
CNPH*6024A** 0.98 1.02 315(A,J)AV066155
CNPH*6124A** 0.98 1.02 315(A,J)AV066155
CNPV*6024A** 0.98 1.02 315(A,J)AV066155
CNPV*6124A** 0.99 1.03 315(A,J)AV066155
CSPH*6012A** 0.98 1.02 315(A,J)AV066155
CNPH*6024A** 0.98 1.07 359BAV060080
CNPH*6124A** 1.00 1.09 359BAV060080
CSPH*6012A** 0.98 1.07 359BAV060080
CAP**6025A** 0.97 1.06 359BAV060100
CNPH*6024A** 0.97 1.06 359BAV060100
CNPH*6124A** 1.00 1.09 359BAV060100
CNPV*6024A** 0.97 1.06 359BAV060100
CNPV*6124A** 1.01 1.10 359BAV060100
CSPH*6012A** 0.97 1.06 359BAV060100
CNPH*6024A** 0.96 1.05 353(A,B)AV048080
CSPH*6012A** 0.97 1.06 353(A,B)AV048080
CAP**6021A** 0.97 1.01 353(A,B)AV060100
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPH*6024A** 0.97 1.01 353(A,B)AV060100
CNPH*6124A** 0.97 1.01 353(A,B)AV060100
CSPH*6012A** 0.98 1.02 353(A,B)AV060100
CAP**6024A** 0.97 1.01 353(A,B)AV060120
CNPH*6024A** 0.97 1.01 353(A,B)AV060120
CNPH*6124A** 0.98 1.02 353(A,B)AV060120
CNPV*6024A** 0.97 1.01 353(A,B)AV060120
CNPV*6124A** 0.99 1.03 353(A,B)AV060120
CSPH*6012A** 0.98 1.02 353(A,B)AV060120
CNPV*6124A** 0.98 1.04 355(A,C)AV060120
CSPH*6012A** 0.97 1.06 355(A,C)AV060120
CAP**6021A** 0.97 1.01 313*AV060110
CNPH*6024A** 0.97 1.01 313*AV060110
CNPH*6124A** 0.98 1.02 313*AV060110
CSPH*6012A** 0.98 1.02 313* AV060110
CAP**6024A** 0.97 1.01 313*AV060135
CNPH*6024A** 0.97 1.01 313*AV060135
CNPH*6124A** 0.97 1.01 313*AV060135
CNPV*6024A** 0.97 1.01 313* AV060135
CNPV*6124A** 0.99 1.03 313* AV060135
CSPH*6012A** 0.98 1.02 313* AV060135
{ Total and sensible capacities are net capacities. Blower motor heat has been subtracted.
} Sensible capacities shown are based on 80_F(27_C) entering air at the indoor coil. For sensible capacities at other than 80_F(27_C), deduct 835 Btuh
(245 kW) per 1000 CFM (480 L / S ) of indoor coil air for each degree below 80_F(27_C) , or add 835 Btuh (245 kW) per 1000 C FM (480 L/S ) of indoor coil air per degree above 80_F(27_C).
# Detailed cooling capacities are based on indoor a nd outdoor unit at the same el eva tion per AHRI standard 210/240 ---2008. If a dditional tubing le ngth and/or indoor unit is located above outdoor un it, a slight variation in capacity may
occur.
225B
