PERFORMANCE DATA (cont)
NET COOLING CAPACITIES (cont)
583A--048
Temp (F)
Air Ent
Condenser
Evaporator Air — Cfm/BF
1400/0.050 1600/0.085 1800/0.119
Evaporator Air — Ewb (F)
62 67 72 62 67 72 62 67 72
85
TC 45.2 49.7 54.7 46.4 50.9 56.0 47.5 51.9 57.1
SHC 41.4 34.6 27.6 44.6 37.2 29.2 47.5 39.6 30.8
kW 4.04 4.08 4.12 4.05 4.09 4.13 4.06 4.10 4.14
95
TC 43.5 47.8 52.5 44.6 48.0 53.7 45.7 49.8 54.6
SHC 40.4 33.7 26.7 43.4 34.9 28.3 45.7 38.6 29.8
kW 4.45 4.50 4.55 4.46 4.62 4.56 4.47 4.53 4.58
105
TC 41.3 45.4 49.8 42.3 46.4 50.9 43.4 47.2 51.7
SHC 39.0 32.5 25.6 41.6 34.9 27.1 43.4 37.2 28.6
kW 4.91 4.95 5.00 4.93 4.97 5.02 4.93 4.98 5.03
115
TC 37.6 42.4 46.4 39.0 43.3 47.5 40.6 44.0 48.3
SHC 35.4 30.9 24.1 38.3 32.9 25.6 40.6 35.0 27.0
kW 5.39 5.46 5.51 5.41 5.48 5.43 5.44 5.49 5.55
125
TC 33.9 36.1 42.5 35.8 37.8 43.4 37.4 38.8 44.1
SHC 27.8 25.5 22.1 33.7 28.0 23.4 37.4 30.1 24.6
kW 6.30 5.94 6.05 6.18 5.97 6.06 6.15 5.98 6.08
583A--060
Temp (F)
Air Ent
Condenser
Evaporator Air — Cfm/BF
1750/0.082 2000/0.130 2250/0.162
Evaporator Air — Ewb (F)
62 67 72 62 67 72 62 67 72
85
TC 55.2 60.9 66.4 56.1 61.5 66.4 56.6 61.6 66.9
SHC 49.9 42.1 33.8 53.2 44.3 33.9 55.9 46.3 35.3
kW 4.92 4.97 5.00 5.14 5.23 5.28 5.41 5.55 5.59
95
TC 52.2 58.0 63.7 53.2 58.5 64.1 53.9 58.4 64.0
SHC 48.2 41.0 32.7 51.8 43.2 33.6 53.9 44.8 34.2
kW 5.39 5.57 5.50 5.64 5.75 5.77 5.90 6.03 6.09
105
TC 49.1 54.4 60.4 49.9 54.9 60.7 50.9 55.0 60.5
SHC 47.3 39.4 31.5 49.9 41.6 32.4 50.9 43.5 33.0
kW 5.87 5.98 6.02 6.13 6.22 6.30 6.34 6.57 6.62
115
TC 45.9 50.2 55.2 46.8 50.3 55.5 47.3 50.2 55.3
SHC 45.3 37.4 29.4 46.8 39.4 29.8 47.3 41.0 30.8
kW 6.39 6.48 6.54 6.57 6.75 6.81 6.85 7.07 7.14
125
TC 42.5 46.5 50.6 43.7 46.9 50.6 44.9 46.2 50.2
SHC 42.5 36.1 27.3 43.7 38.4 28.2 44.9 39.5 28.6
kW 7.03 7.13 7.13 7.22 7.38 7.40 7.51 7.67 7.72
LEGEND
BF — Bypass Factor
Ewb — Entering Wet-Bulb
kW — Total Unit Power Input
SHC — Sensible Heat Capacity (1000 Btuh)
TC — Total Capacity (1000 Btuh) (net)
NOTES:
1. Ratings are net; they account for the effects of the evaporator-fan motor power and heat.
2. Direct interpolation is permissible. Do not extrapolate.
3. The following formulas may be used:
sensible capacity (Btuh)
t=t −
ldb edb
1.10 x cfm
t = Wet-bulb temperature corresponding to enthalpy of air leaving
lwb
evaporator coil (h )
lwb
total capacity (Btuh)
h=h −
lwb ewb
4.5 x cfm
Where: h = Enthalpy of air entering evaporator coil
ewb
4. The SHC is based on 80 F edb temperature of air entering evaporator coil.
Below 80 F edb, subtract (corr factor x cfm) from SHC.
Above 80 F edb, add (corr factor x cfm) to SHC.
Correction Factor = 1.10 x (1 − BF) x (edb − 80).
14
