UNIT
538S
_
ABCDEFGH
Ft-in. mm Ft-in. mm Ft-in. mm Ft-in. mm Ft-in. mm Ft-in. mm Ft-in. mm Ft-in. mm
024 2-1
1
⁄ 8 638 3-0
15
⁄ 16 938 1-2
9
⁄ 16 370 1-4 406 1-11
7
⁄ 16 595 1-5
3
⁄ 16 437 1-5
1
⁄ 2 445 1-8
1
⁄ 8 511
048 3-1
3
⁄ 16 945 3-8
9
⁄ 16 1132 1-5
1
⁄ 16 433 1-6
7
⁄ 16 468 2-6
1
⁄ 2 775 1-7
5
⁄ 8 499 2-5
5
⁄ 8 753 2-8
3
⁄ 16 818
UNIT
538S
_
J K L M N R S OPERATING WEIGHT
Ft-in. mm Ft-in. mm Ft-in. mm Ft-in. mm Ft-in. mm Ft-in. mm Ft-in. mm Lb Kg
024 1-2
7
⁄ 16 367 0-6
3
⁄ 4 171 1-0 305 0-0
5
⁄ 8 16 0-0
3
⁄ 8 10 — — — — 159 72.0
048 1-2
3
⁄ 4 375 0-7
1
⁄ 2 191 1-6 457 0-0
5
⁄ 8 16 0-0
3
⁄ 8 10 0-6
5
⁄ 16 160 0-5
7
⁄ 8 149 292 132.3
UNIT
538S
_
MINIMUM MOUNTING PAD DIMENSIONS
SUPPORT FEET SNOW STAND ICE STAND
Ft-in. mm Ft-in. mm Ft-in. mm
024 1-11 x 3-6 584 x 1067 2-2 x 3-6 660 x 1067 2-2 x 3-6 660 x 1067
048 2- 0 x 4-2 610 x 1270 2-4 x 4-4 711 x 1270 2-2 x 4-2 660 x 1270
NOTES:
1. Required clearances: with coil facing wall; allow 6 in. minimum clear-
ance on coil side and coil end, and 3 ft minimum clearance on com-
pressor end and fan side. With fan facing wall; allow 8 in. minimum
clearance on fan side and coil end, and 3 ft minimum clearance on
compressor end and coil side. With multi-unit application: arrange
units so discharge of one does not enter inlet of another.
2. Dimensions in [ ] are in millimeters.
3. Center of gravity .
4. Thermistors are used with 619B and 619C fan coils only.
Fig. 2 — Base Unit Dimensional Drawing
—3—
