LEGEND
M—Motor
TXV Thermostatic Expansion Valve
Field-Supplied Tubing
NOTE: Insulate ALL lines between outdoor condensing unit and indoor fan coil units.
Fig. 5 Refrigerant Tubing Schematic (538S
_
048 Shown)
—5—
