SPECIFICATIONS - HEAT PUMP UNITS (MAQ SERIES)
System
Size 9 12 9 12 18 24 30
Outdoor Model 538PAQ009RBMA 538PAQ012RBMA 538PEQ009RBMA 538PEQ012RBMA 538PEQ018RBMA 538PEQ024RBMA 538PEQ030RBMA
Indoor Model 619PAQ009BBMA 619PAQ012BBMA 619PEQ009BBMA 619PEQ012BBMA 619PEQ018BBMA 619PEQ024BBMA 619PEQ030BBMA
Energy Star YES YES YES YES YES YES NO
Performance
Cooling Rated Capacity Btu/h 9,000 12,000 9,000 12,000 17,500 23,000 30,000
Cooling Cap. Range Min - Max Btu/h 3500~11000 4000~13000 3500~11000 4000~13000 4500~18000 5500~23500 8000~30500
SEER 23.5 21.5 23.5 21.5 19.5 20.0 16.5
EER 14.5 13 14.5 13 12.5 12.5 9.5
Heating Rated Capacity Btu/h 10,000 12,000 10,000 12,000 18,000 25,000 32,000
Heating Cap. Range Min - Max Btu/h 4,500~11,500 5,000~13,500 4,500~11,500 5,000~13,500 5,500~19,000 6,000~26,000 9,000~34,000
HSPF 10.0 10.0 10.0 10.0 9.6 10.0 9.6
COP W/W 3.36 3.22 3.66 3.36 3.36 3.22 2.92
Controls
Wireless Remote Controller (°F/°C Convertible) Standard
Wired Remote Controller (°F/°C Convertible) Optional
Operating
Range
Cooling Outdoor DB Min - Max °F 4~122 4~122 4~122 4~122 4~122 4~122 4~122
Heating Outdoor DB Min - Max °F 4~86 4~86 4~86 4~86 4~86 4~86 4~86
Cooling Indoor DB Min -Max °F 63~90 63~90 63~90 63~90 63~90 63~90 63~90
Heating Indoor DB Min -Max °F 32~86 32~86 32~86 32~86 32~86 32~86 32~86
Piping
Total Piping Length Ft. 82 82 82 82 98 98 164
Piping Lift
*
Ft. 32 32 32 32 65 65 82
Pipe Connection Size - Liquid In. 1/4 1/4 1/4 1/4 1/4 3/8 3/8
Pipe Connection Size - Suction In. 3/8 1/2 3/8 1/2 1/2 5/8 5/8
Refrigerant
Type R410A
Design Pressure PSIG 550 550 550 550 550 550 550
Metering Device Electronic Expansion Valve Capillary Tube
Charge Lb. 2.76 2.76 2.76 2.76 4.19 5.18 6.62
Outdoor Coil
Face Area Sq. Ft. 9.2 9.2 9.2 9.2 16.0 21.1 17.2
No. Rows 2 2 2 2 2 3 3
Fins per inc h 21 21 21 21 18 18 17
Circuits 4 4 4 4 6 8 6
Indoor Coil
Face Area (sq. ft.) Sq. Ft. 2.2 2.2 2.2 2.2 2.6 3.7 3.7
No. Rows 2 2 2 2 2 3 3
Fins per inc h 20 20 20 20 20 18 18
Circuits 3 3 3 3 4 7 7
Compressor
Type Hermetic Rotary DC Inverter Compressor
Model ASM98D1UFZA ASM108D1UFZA ASM98D1UFZA ASM108D1UFZA ASM135D23UFZ DA250S2C-30MT TNB306FPGMC-L
Oil Type VG74 VG74 VG74 VG74 VG74 VG74 FV50S
Oil Charge Fl. Oz. 12.5 12.5 12.5 12.5 15.2 27.7 36.2
Rated Current RLA 5.3 5.7 5.3 5.7 7.3 8.8 13.5
Electrical
Voltage, Phase, Cycle V/Ph/Hz 115-1-60 115-1-60 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60
Power Supply Indoor unit powered from outdoor unit
MCA A. 15 15 15 15 13 15 20
MOCP - Fuse Rating A. 20 20 15 15 20 25 30
Outdoor
Unit Width In. 31.9 31.9 .9 31.9 33.3 37.2 37.2
Unit Height In. 22.0 22.0 .0 22.0 .6 31.9 31.9
Unit Depth In. 12.2 12.2 .2 12.2 .6 15.6 15.6
Net Weight Lbs. 82.5 82.5 82.5 82.5 102.5 137.6 157.6
Airflow CFM 1200 1200 1200 1200 1390 2130 2130
Sound Pressure dB(A) 56 56 56 56 59 60 63
Indoor
Unit Width In. 32.9 32.9 32.9 32.9 39.0 46.7 46.7
Unit Height In. 11.0 11.0 11.0 11.0 12.4 13.4 13.4
Unit Depth In. 7.8 7.8 7.8 7.8 8.6 10.2 10.2
Net Weight Lbs. 19.2 19.2 19.2 19.2 26.5 40.1 40.1
Number of Fan Speeds 4 4 4 4 4 4 4
Airflow (lowest to highest) CFM 210/290/360/380 210/300/360/380 210/290/360/380 210/300/360/380 310/450/650/680 520/620/780/870 520/620/780/870
Sound Pressure (lowest to highest) dB(A) 27/34/42 27/34/42 27/34/42 27/34/42 33/40/46 39/45/50 39/45/50
Air throw Data Ft. 23 23 23 23 30 36 36
Condensing unit above or below indoor unit
