FURNACE SIZE
A B C D
SHIP WT.
LB (KG)
CABINET WIDTH OUTLET WIDTH BOTTOM INLET WIDTH AIR INTAKE
30040
14---3/16 (361) 12---1/2 (319) 12---9/16 (322) 7---1/8 (181)
121.0 (55.0)
36060 125.0 (56.8)
36040
17---1/2 (445) 15---7/8 (403) 16 (406) 8---3/4 (222)
132.0 (60.0)
48060 142.0 (64.5)
48080 151.0 (68.6)
60080
21 (533) 19---3/8 (492) 19---1/2 (495) 10---1/2 (267)
158.5 (72.0)
48100 166.5 (75.7)
60100 166.5 (75.7)
60120 24---1/2 (622) 22---7/8 (581) 23 (584) 12---1/4 (311) 184.0 (83.6)
Fig. 1 -- Dimensional Drawing
