Bryant CK3B - CK3 B Unit Dimensions and Weights; Dimensional Diagram and Key Labels; Detailed Dimensions and Shipping Weights by Model

—3—
A97521
DIMENSIONS (In.)
UNIT
ABCDE
SHIPPING
WEIGHT
In. In. In. In. In. Lb
CK3BXA024 17-9/16 19-1/16 10-1/16 5/8 16 36.0
CK3BXA030 17-9/16 19-1/16 10-1/16 3/4 16 39.5
CK3BXA036 17-9/16 22-1/16 10-1/4 3/4 16 45.5
CK3BXA042 21-1/16 22-1/16 10-1/4 7/8 19-1/2 47.0
CK3BXA048 21-1/16 22-1/16 10-1/4 7/8 19-1/2 51.0
CK3BXA060 24-9/16 28-1/8 13-3/6 7/8 23 64.0
C
A
D
SUCTION LINE
9
1
⁄
8
″
4
3
⁄
8
″
3″
3
⁄
8
IN. 
LIQUID
LINE
3
⁄
4
IN. NPT DRAIN
B
1
11
⁄
16
″
20
3
⁄
4
″
3
15
⁄
16
″
1
1
⁄
2
″
3
⁄
8
″
E
OPTIONAL
DUCT
FILLER
PANEL
18
7
⁄
8
″
2
7
⁄
8
″
1
1
⁄
4
″
FRONT RIGHT SIDE
DUCT
OPENING
TYPICAL
BOTH
ENDS
