10
* Base unit operating weight does not include weight of options.
CONDENSER FAN AND MOTOR
Qty / Motor Drive Type 1 / Direct
Motor HP/RPM
1
/
4
/ 1100
1
/
4
/ 1100
1
/
4
/ 1100
1
/
4
/ 1100
Fan Diameter (in.) 23
FILTERS
RA Filter Qty / Size (in.) 2 / 16x25x2
OA Inlet Screen Qty / Size (in.) 1 / 20x24x1
582/559K 3 TO 4 TON PHYSICAL DATA (cont)
582/559K UNIT 582/559K*04A/B/C 582/559K*04G/H/J 582/559K*05A/B/C 582/559K*05G/H/J
Physical data (cont)
