559K*04 MCA MOCP ELECTRICAL DATA
559K
UNIT
SIZE
NOM.
V-Ph-Hz
IFM
TYPE
ELECTRIC HEATER NO CONVENIENCE OUTLET or UNPOWERED CONVENIENCE OUTLET
CRHEATER
***A00
NOM
(kW)
FLA
NO POWER EXHAUST w/ POWER EXHAUST (powered from unit)
MCA
FUSE
OR
HACR
BRKR
DISCONNECT SIZE
MCA
FUSE
OR
HACR
BRKR
DISCONNECT SIZE
FLA LRA FLA LRA
*04
208/230-1-60
STD
NONE — — 26 30 24 94 27 40 27 96
323A 3.3/4.4 15.9/18.3 26/29 30/30 24/26 94/94 28/31 40/40 27/28 96/96
324A 4.9/6.5 23.5/27.1 35/40 40/40 32/36 94/94 38/42 40/45 34/38 96/96
325A 6.5/8.7 31.4/36.3 45/51 45/60 41/47 94/94 47/54 50/60 43/49 96/96
326A 7.9/10.5 37.9/43.8 53/61 60/70 49/55 94/94 56/63 60/70 51/58 96/96
327A 9.8/13.0 46.9/54.2 64/74 70/80 59/67 94/94 67/76 70/80 61/69 96/96
MED
NONE — — 26 30 25 95 28 40 27 97
323A 3.3/4.4 15.9/18.3 27/30 30/30 25/27 95/95 29/32 40/40 27/29 97/97
324A 4.9/6.5 23.5/27.1 36/41 40/45 33/37 95/95 39/43 40/45 35/39 97/97
325A 6.5/8.7 31.4/36.3 46/52 50/60 42/48 95/95 48/55 50/60 44/50 97/97
326A 7.9/10.5 37.9/43.8 54/62 60/70 49/56 95/95 57/64 60/70 52/58 97/97
327A 9.8/13.0 46.9/54.2 65/75 70/80 60/68 95/95 68/77 70/80 62/70 97/97
HIGH
NONE — — 29 40 28 98 30 45 30 100
323A 3.3/4.4 15.9/18.3 29/32 40/40 28/29 98/98 32/35 45/45 30/32 100/100
324A 4.9/6.5 23.5/27.1 39/43 40/45 35/40 98/98 41/46 45/50 38/42 100/100
325A 6.5/8.7 31.4/36.3 49/55 50/60 45/50 98/98 51/57 60/60 47/52 100/100
326A 7.9/10.5 37.9/43.8 57/64 60/70 52/59 98/98 59/67 60/70 54/61 100/100
327A 9.8/13.0 46.9/54.2 68/77 70/80 62/71 98/98 71/80 80/80 65/73 100/100
208/230-3-60
STD
NONE — — 19 25 19 83 21 30 21 85
323A 3.3/4.4 9.2/10.6 19/19 25/25 19/19 83/83 21/21 30/30 21/21 85/85
324A 4.9/6.5 13.6/15.6 23/25 25/25 21/23 83/83 25/28 30/30 23/25 85/85
325A 6.5/8.7 18.1/20.9 28/32 30/35 26/29 83/83 31/34 35/35 28/31 85/85
326A 7.9/10.5 21.9/25.3 33/37 35/40 30/34 83/83 36/40 40/40 32/36 85/85
328A 12.0/16.0 33.4/38.5 48/54 50/60 43/49 83/83 50/56 50/60 46/51 85/85
MED
NONE — — 20 30 20 84 22 30 22 86
323A 3.3/4.4 9.2/10.6 20/20 30/30 20/20 84/84 22/22 30/30 22/22 86/86
324A 4.9/6.5 13.6/15.6 24/26 30/30 22/24 84/84 26/29 30/30 24/26 86/86
325A 6.5/8.7 18.1/20.9 29/33 30/35 27/30 84/84 32/35 35/35 29/32 86/86
326A 7.9/10.5 21.9/25.3 34/38 35/40 31/35 84/84 37/41 40/45 33/37 86/86
328A 12.0/16.0 33.4/38.5 49/55 50/60 44/50 84/84 51/57 60/60 46/52 86/86
HIGH
NONE — — 22 30 22 87 24 30 24 89
323A 3.3/4.4 9.2/10.6 22/23 30/30 22/22 87/87 24/25 30/30 24/24 89/89
324A 4.9/6.5 13.6/15.6 27/29 30/30 24/26 87/87 29/31 30/35 26/29 89/89
325A 6.5/8.7 18.1/20.9 32/36 35/40 29/32 87/87 35/38 35/40 31/35 89/89
326A 7.9/10.5 21.9/25.3 37/41 40/45 34/37 87/87 39/44 40/45 36/40 89/89
328A 12.0/16.0 33.4/38.5 51/58 60/60 47/53 87/87 54/60 60/60 49/55 89/89
460-3-60
STD
NONE — — 10 15 9 42 11 15 10 43
333A 6.0 7.2 11 15 10 42 12 15 11 43
334A 8.8 10.6 1515144216201543
335A 11.5 13.8 19 20 17 42 20 25 18 43
336A 14.0 16.8 23 25 21 42 24 25 22 43
MED
NONE — — 10 15 9 42 11 15 10 43
333A 6.0 7.2 11 15 10 42 12 15 11 43
334A 8.8 10.6 1515144216201543
335A 11.5 13.8 19 20 17 42 20 25 18 43
336A 14.0 16.8 23 25 21 42 24 25 22 43
HIGH
NONE — — 10 15 10 42 11 15 11 43
333A 6.0 7.2 12 15 10 42 13 15 11 43
334A 8.8 10.6 1620144217201543
335A 11.5 13.8 20 20 18 42 21 25 19 43
336A 14.0 16.8 24 25 21 42 25 25 22 43
575-3-60
STD
NONE— — 715641915943
339A 10.0 9.6 14 15 12 41 16 20 14 43
340A 15.0 14.4 20 20 18 41 22 25 20 43
MED
NONE— — 715641915943
339A 10.0 9.6 14 15 12 41 16 20 14 43
340A 15.0 14.4 20 20 18 41 22 25 20 43
HIGH
NONE— — 715741915943
339A 10.0 9.6 14 15 13 41 17 20 15 43
340A 15.0 14.4 20 20 18 41 23 25 20 43
Electrical data (cont)
