Bryant LEGACY 582K User Manual

102
559K*04 MCA MOCP ELECTRICAL DATA (cont)
559K
UNIT
SIZE
NOM.
V-Ph-Hz
IFM
TYPE
ELECTRIC HEATER w/ POWERED CONVENIENCE OUTLET
CRHEATER
***A00
NOM
(kW)
FLA
NO POWER EXHAUST w/ POWER EXHAUST (powered from unit)
MCA
FUSE
OR
HACR
BRKR
DISCONNECT SIZE
MCA
FUSE
OR
HACR
BRKR
DISCONNECT SIZE
FLA LRA FLA LRA
*04
208/230-3-60
STD
NONE — — 24 30 24 88 26 30 26 90
323A 3.3/4.4 9.2/10.6 24/25 30/30 24/24 88/88 26/27 30/30 26/26 90/90
324A 4.9/6.5 13.6/15.6 29/31 30/35 26/28 88/88 31/34 35/35 28/31 90/90
325A 6.5/8.7 18.1/20.9 34/38 35/40 31/35 88/88 37/40 40/40 33/37 90/90
326A 7.9/10.5 21.9/25.3 39/43 40/45 36/40 88/88 42/46 45/50 38/42 90/90
328A 12.0/16.0 33.4/38.5 54/60 60/60 49/55 88/88 56/62 60/70 51/57 90/90
MED
NONE — — 25 30 25 89 27 30 27 91
323A 3.3/4.4 9.2/10.6 25/26 30/30 25/25 89/89 27/28 30/30 27/27 91/91
324A 4.9/6.5 13.6/15.6 30/32 30/35 27/29 89/89 32/35 35/35 29/32 91/91
325A 6.5/8.7 18.1/20.9 35/39 40/40 32/35 89/89 38/41 40/45 34/38 91/91
326A 7.9/10.5 21.9/25.3 40/44 40/45 37/40 89/89 43/47 45/50 39/43 91/91
328A 12.0/16.0 33.4/38.5 55/61 60/70 50/56 89/89 57/63 60/70 52/58 91/91
HIGH
NONE — — 27 30 28 92 29 35 30 94
323A 3.3/4.4 9.2/10.6 27/29 30/30 28/28 92/92 29/31 35/35 30/30 94/94
324A 4.9/6.5 13.6/15.6 33/35 35/35 30/32 92/92 35/37 35/40 32/34 94/94
325A 6.5/8.7 18.1/20.9 38/42 40/45 35/38 92/92 41/44 45/45 37/40 94/94
326A 7.9/10.5 21.9/25.3 43/47 45/50 39/43 92/92 45/50 45/50 41/45 94/94
328A 12.0/16.0 33.4/38.5 57/64 60/70 52/58 92/92 60/66 60/70 55/60 94/94
460-3-60
STD
NONE — — 12 15 12 44 13 15 13 45
333A 6.0 7.2 14 15 12 44 15 15 13 45
334A 8.8 10.6 1820164419201745
335A 11.5 13.8 22 25 20 44 23 25 21 45
336A 14.0 16.8 26 30 23 44 27 30 24 45
MED
NONE — — 12 15 12 44 13 15 13 45
333A 6.0 7.2 14 15 12 44 15 15 13 45
334A 8.8 10.6 1820164419201745
335A 11.5 13.8 22 25 20 44 23 25 21 45
336A 14.0 16.8 26 30 23 44 27 30 24 45
HIGH
NONE — — 12 15 12 44 13 15 13 45
333A 6.0 7.2 14 15 13 44 16 20 14 45
334A 8.8 10.6 1920174420201845
335A 11.5 13.8 23 25 20 44 24 25 22 45
336A 14.0 16.8 26 30 24 44 28 30 25 45
575-3-60
STD
NONE— — 91584311151045
339A 10.0 9.6 16 20 14 43 18 20 16 45
340A 15.0 14.4 22 25 20 43 24 25 22 45
MED
NONE— — 91584311151045
339A 10.0 9.6 16 20 14 43 18 20 16 45
340A 15.0 14.4 22 25 20 43 24 25 22 45
HIGH
NONE— — 91594311151145
339A 10.0 9.6 16 20 15 43 19 20 17 45
340A 15.0 14.4 22 25 20 43 25 25 22 45
Electrical data (cont)
