Bryant LEGACY 582K User Manual

103
559K*05 MCA MOCP ELECTRICAL DATA
559K
UNIT
SIZE
NOM.
V-Ph-Hz
IFM
TYPE
ELECTRIC HEATER NO CONVENIENCE OUTLET or UNPOWERED CONVENIENCE OUTLET
CRHEATER
***A00
NOM
(kW)
FLA
NO POWER EXHAUST w/ POWER EXHAUST (powered from unit)
MCA
FUSE
OR
HACR
BRKR
DISCONNECT SIZE
MCA
FUSE
OR
HACR
BRKR
DISCONNECT SIZE
FLA LRA FLA LRA
*05
208/230-1-60
STD
NONE — — 31 50 30 141 33 50 32 143
323A 3.3/4.4 15.9/18.3 31/31 50/50 30/30 141/141 33/33 50/50 32/32 143/143
325A 6.5/8.7 31.4/36.3 46/52 50/60 42/47 141/141 48/54 50/60 44/50 143/143
327A 9.8/13.0 46.9/54.2 65/74 70/80 60/68 141/141 68/77 70/80 62/70 143/143
329A 13.1/17.4 62.8/72.5 85/97 90/100 78/89 141/141 88/100 90/100 80/91 143/143
330A* 14.4/19.2 69.3/80.0 93/107 100/110 85/98 141/141 96/109 100/110 88/100 143/143
331A† 15.8/21.0 75.8/87.5 101/116 110/125 93/106 141/141 104/118 110/125 95/109 143/143
MED
NONE — — 34 50 32 144 35 50 35 146
323A 3.3/4.4 15.9/18.3 34/34 50/50 32/32 144/144 35/35 50/50 35/35 146/146
325A 6.5/8.7 31.4/36.3 49/55 50/60 44/50 144/144 51/57 60/60 46/52 146/146
327A 9.8/13.0 46.9/54.2 68/77 70/80 62/70 144/144 70/79 70/80 64/73 146/146
329A 13.1/17.4 62.8/72.5 88/100 90/100 80/92 144/144 90/102 90/110 83/94 146/146
330A 14.4/19.2 69.3/80.0 96/109 100/110 88/100 144/144 98/112 100/125 90/102 146/146
331A† 15.8/21.0 75.8/87.5 104/119 110/125 95/109 144/144 106/121 110/125 98/111 146/146
HIGH
NONE — — 36 50 35 147 38 50 37 149
323A 3.3/4.4 15.9/18.3 36/36 50/50 35/35 147/147 38/38 50/50 37/37 149/149
325A 6.5/8.7 31.4/36.3 51/57 60/60 47/52 147/147 54/60 60/60 49/55 149/149
327A 9.8/13.0 46.9/54.2 71/80 80/80 65/73 147/147 73/82 80/90 67/75 149/149
329A 13.1/17.4 62.8/72.5 90/103 100/110 83/94 147/147 93/105 100/110 85/96 149/149
330A* 14.4/19.2 69.3/80.0 99/112 100/125 90/103 147/147 101/114 110/125 92/105 149/149
331A† 15.8/21.0 75.8/87.5 107/121 110/125 98/111 147/147 109/124 110/125 100/113 149/149
208/230-3-60
STD
NONE — — 24 30 23 94 26 30 25 96
323A 3.3/4.4 9.2/10.6 24/24 30/30 23/23 94/94 26/26 30/30 25/25 96/96
324A 4.9/6.5 13.6/15.6 24/26 30/30 23/24 94/94 26/29 30/30 25/26 96/96
325A 6.5/8.7 18.1/20.9 29/33 30/35 27/30 94/94 32/35 35/35 29/32 96/96
328A 12.0/16.0 33.4/38.5 48/55 50/60 44/50 94/94 51/57 60/60 46/52 96/96
330A 14.4/19.2 40.0/46.2 57/64 60/70 52/59 94/94 59/67 60/70 54/61 96/96
331A† 15.8/21.0 43.8/50.5 61/70 70/70 56/64 94/94 64/72 70/80 58/66 96/96
MED
NONE — — 26 30 26 97 28 40 28 99
323A 3.3/4.4 9.2/10.6 26/26 30/30 26/26 97/97 28/28 40/40 28/28 99/99
324A 4.9/6.5 13.6/15.6 26/29 30/30 26/26 97/97 29/31 40/40 28/28 99/99
325A 6.5/8.7 18.1/20.9 32/35 35/35 29/32 97/97 34/38 40/40 31/34 99/99
328A 12.0/16.0 33.4/38.5 51/57 60/60 47/52 97/97 53/60 60/60 49/55 99/99
330A* 14.4/19.2 40.0/46.2 59/67 60/70 54/61 97/97 62/69 70/70 56/63 99/99
331A† 15.8/21.0 43.8/50.5 64/72 70/80 59/66 97/97 66/75 70/80 61/68 99/99
HIGH
NONE — — 25 30 24 95 26 30 26 97
323A 3.3/4.4 9.2/10.6 25/25 30/30 24/24 95/95 26/26 30/30 26/26 97/97
324A 4.9/6.5 13.6/15.6 25/27 30/30 24/24 95/95 27/29 30/30 26/26 97/97
325A 6.5/8.7 18.1/20.9 30/33 30/35 27/30 95/95 32/36 35/40 29/33 97/97
328A 12.0/16.0 33.4/38.5 49/55 50/60 45/51 95/95 51/58 60/60 47/53 97/97
330A* 14.4/19.2 40.0/46.2 57/65 60/70 52/59 95/95 60/67 60/70 55/62 97/97
331A† 15.8/21.0 43.8/50.5 62/70 70/80 57/64 95/95 64/73 70/80 59/67 97/97
460-3-60
STD
NONE — — 10 15 9 45 11 15 11 46
333A 6.0 7.2 11 15 10 45 12 15 11 46
335A 11.5 13.8 19 20 17 45 20 25 18 46
336A 14.0 16.8 23 25 21 45 24 25 22 46
337A 21.5 25.9 34 35 31 45 36 40 32 46
MED
NONE — — 11 15 10 45 12 15 11 46
333A 6.0 7.2 12 15 10 45 13 15 11 46
335A 11.5 13.8 20 20 18 45 21 25 19 46
336A 14.0 16.8 24 25 21 45 25 25 22 46
337A 21.5 25.9 35 35 32 45 36 40 33 46
HIGH
NONE — — 12 15 11 47 13 15 12 48
333A 6.0 7.2 13 15 11 47 14 15 12 48
335A 11.5 13.8 21 25 19 47 22 25 20 48
336A 14.0 16.8 25 25 22 47 26 30 23 48
337A 21.5 25.9 36 40 33 47 37 40 34 48
Electrical data (cont)
