107
559K*06 MCA MOCP ELECTRICAL DATA (cont)
559K
UNIT
SIZE
NOM.
V-Ph-Hz
IFM
TYPE
ELECTRIC HEATER w/ POWERED CONVENIENCE OUTLET
CRHEATER
***A00
NOM
(kW)
FLA
NO POWER EXHAUST w/ POWER EXHAUST (powered from unit)
MCA
FUSE
OR
HACR
BRKR
DISCONNECT SIZE
MCA
FUSE
OR
HACR
BRKR
DISCONNECT SIZE
FLA LRA FLA LRA
*06
208/230-3-60
STD
NONE — — 34 45 34 129 36 50 36 131
324A 4.9/6.5 13.6/15.6 34/35 45/45 34/34 129/129 36/37 50/50 36/36 131/131
326A 7.9/10.5 21.9/25.3 43/47 45/50 39/43 129/129 45/49 50/50 41/45 131/131
328A 12.0/16.0 33.4/38.5 57/64 60/70 52/58 129/129 60/66 60/70 54/60 131/131
331A 15.8/21.0 43.8/50.5 70/79 70/80 64/72 129/129 73/81 80/90 66/74 131/131
332A 18.4/24.5 51.1/58.9 79/89 80/90 73/82 129/129 82/91 90/100 75/84 131/131
MED
NONE — — 36 50 36 132 38 50 38 134
324A 4.9/6.5 13.6/15.6 36/37 50/50 36/36 132/132 38/40 50/50 38/38 134/134
326A 7.9/10.5 21.9/25.3 45/50 50/50 41/45 132/132 48/52 50/60 43/47 134/134
328A 12.0/16.0 33.4/38.5 60/66 60/70 55/60 132/132 62/68 70/70 57/63 134/134
331A 15.8/21.0 43.8/50.5 73/81 80/90 66/74 132/132 75/83 80/90 69/76 134/134
332A 18.4/24.5 51.1/58.9 82/92 90/100 75/84 132/132 84/94 90/100 77/86 134/134
HIGH
NONE — — 33 45 33 128 35 50 35 130
324A 4.9/6.5 13.6/15.6 33/34 45/45 33/33 128/128 35/36 50/50 35/35 130/130
326A 7.9/10.5 21.9/25.3 42/46 45/50 38/42 128/128 44/49 50/50 40/44 130/130
328A 12.0/16.0 33.4/38.5 56/63 60/70 51/57 128/128 59/65 60/70 54/59 130/130
331A 15.8/21.0 43.8/50.5 69/78 70/80 63/71 128/128 72/80 80/80 66/73 130/130
332A 18.4/24.5 51.1/58.9 78/88 80/90 72/81 128/128 81/91 90/100 74/83 130/130
460-3-60
STD
NONE — — 15 20 14 58 16 20 16 59
333A 6.0 7.2 15 20 14 58 16 20 16 59
335A 11.5 13.8 23 25 20 58 24 25 22 59
336A 14.0 16.8 26 30 24 58 28 30 25 59
337A 21.5 25.9 38 40 34 58 39 40 35 59
338A 24.0 28.9 41 45 38 58 43 45 39 59
MED
NONE — — 15 20 15 59 16 20 16 60
333A 6.0 7.2 15 20 15 59 16 20 16 60
335A 11.5 13.8 23 25 21 59 24 25 22 60
336A 14.0 16.8 27 30 24 59 28 30 25 60
337A 21.5 25.9 38 40 35 59 39 40 36 60
338A 24.0 28.9 42 45 38 59 43 45 39 60
HIGH
NONE — — 16 20 16 60 17 20 17 61
333A 6.0 7.2 16 20 16 60 17 20 17 61
335A 11.5 13.8 24 25 22 60 26 30 23 61
336A 14.0 16.8 28 30 25 60 29 30 27 61
337A 21.5 25.9 39 40 36 60 41 45 37 61
338A 24.0 28.9 43 45 39 60 44 45 40 61
575-3-60
STD
NONE — — 11 15 11 45 13 15 13 47
340A 15.0 14.4 22 25 20 45 25 25 22 47
341A 21.0 20.2 30 30 27 45 32 35 29 47
MED
NONE — — 12 15 12 46 14 15 14 48
340A 15.0 14.4 23 25 21 46 25 30 23 48
341A 21.0 20.2 30 30 27 46 33 35 30 48
HIGH
NONE — — 13 15 12 47 14 20 14 49
340A 15.0 14.4 24 25 22 47 26 30 24 49
341A 21.0 20.2 31 35 28 47 34 35 30 49
Electrical data (cont)
