559K*07 MCA MOCP ELECTRICAL DATA
559K
UNIT
SIZE
NOM.
V-Ph-Hz
IFM
TYPE
ELECTRIC HEATER NO CONVENIENCE OUTLET or UNPOWERED CONVENIENCE OUTLET
CRHEATER
***A00
NOM
(kW)
FLA
NO POWER EXHAUST w/ POWER EXHAUST (powered from unit)
MCA
FUSE
OR
HACR
BRKR
DISCONNECT SIZE
MCA
FUSE
OR
HACR
BRKR
DISCONNECT SIZE
FLA LRA FLA LRA
*07
208/230-3-60
STD
NONE — — 33 50 32 153 35 50 35 155
324A 4.9/6.5 13.6/15.6 33/33 50/50 32/32 153/153 35/35 50/50 35/35 155/155
326A 7.9/10.5 21.9/25.3 39/44 50/50 36/40 153/153 42/46 50/50 38/42 155/155
328A 12.0/16.0 33.4/38.5 54/60 60/60 49/55 153/153 56/62 60/70 51/57 155/155
331A 15.8/21.0 43.8/50.5 67/75 70/80 61/69 153/153 69/77 70/80 63/71 155/155
332A 18.4/24.5 51.1/58.9 76/86 80/90 69/78 153/153 78/88 80/90 72/81 155/155
MED
NONE — — 29 45 28 148 31 45 30 150
324A 4.9/6.5 13.6/15.6 29/29 45/45 28/28 148/148 31/31 45/45 30/30 150/150
326A 7.9/10.5 21.9/25.3 35/39 45/45 32/35 148/148 37/41 45/45 34/38 150/150
328A 12.0/16.0 33.4/38.5 49/55 50/60 45/51 148/148 51/58 60/60 47/53 150/150
331A 15.8/21.0 43.8/50.5 62/70 70/80 57/64 148/148 64/73 70/80 59/67 150/150
332A 18.4/24.5 51.1/58.9 71/81 80/90 65/74 148/148 74/83 80/90 67/76 150/150
HIGH
NONE — — 30 45 29 149 32 45 32 151
324A 4.9/6.5 13.6/15.6 30/30 45/45 29/29 149/149 32/32 45/45 32/32 151/151
326A 7.9/10.5 21.9/25.3 36/40 45/45 33/37 149/149 38/43 45/45 35/39 151/151
328A 12.0/16.0 33.4/38.5 50/57 50/60 46/52 149/149 53/59 60/60 48/54 151/151
331A 15.8/21.0 43.8/50.5 63/72 70/80 58/66 149/149 66/74 70/80 60/68 151/151
332A 18.4/24.5 51.1/58.9 72/82 80/90 66/75 149/149 75/85 80/90 68/77 151/151
460-3-60
STD
NONE — — 14 20 13 71 15 20 14 72
333A 6.0 7.2 1420137115201472
335A11.513.8 2020187122251972
336A14.016.8 2425227125252372
337A21.525.9 3540327137403372
338A24.028.9 3940367140453772
MED
NONE — — 14 20 14 72 15 20 15 73
333A 6.0 7.2 1420147215201573
335A11.513.8 2125197222252073
336A14.016.8 2525227226302373
337A21.525.9 3640337237403473
338A24.028.9 4040367241453773
HIGH
NONE — — 15 20 14 72 16 20 15 73
333A 6.0 7.2 1520147216201573
335A11.513.8 2225197223252173
336A14.016.8 2525237227302473
337A21.525.9 3740337238403573
338A24.028.9 4045377242453873
575-3-60
STD
NONE — — 11 15 10 60 13 15 12 62
340A15.014.4 2125196023252162
341A21.020.2 2830266031352862
MED
NONE — — 11 15 11 60 13 15 13 62
340A15.014.4 2125196024252162
341A21.020.2 2930266031352862
HIGH
NONE — — 12 15 11 61 14 15 13 63
340A15.014.4 2225206124252263
341A21.020.2 2930266131352963
