109
559K*07 MCA MOCP ELECTRICAL DATA (cont)
559K
UNIT
SIZE
NOM.
V-Ph-Hz
IFM
TYPE
ELECTRIC HEATER w/ POWERED CONVENIENCE OUTLET
CRHEATER
***A00
NOM
(kW)
FLA
NO POWER EXHAUST w/ POWER EXHAUST (powered from unit)
MCA
FUSE
OR
HACR
BRKR
DISCONNECT SIZE
MCA
FUSE
OR
HACR
BRKR
DISCONNECT SIZE
FLA LRA FLA LRA
*07
208/230-3-60
STD
NONE — — 38 50 38 158 40 50 40 160
324A 4.9/6.5 13.6/15.6 38/38 50/50 38/38 158/158 40/40 50/50 40/40 160/160
326A 7.9/10.5 21.9/25.3 45/50 50/50 41/45 158/158 48/52 50/60 43/47 160/160
328A 12.0/16.0 33.4/38.5 60/66 60/70 55/60 158/158 62/68 70/70 57/63 160/160
331A 15.8/21.0 43.8/50.5 73/81 80/90 66/74 158/158 75/83 80/90 69/76 160/160
332A 18.4/24.5 51.1/58.9 82/92 90/100 75/84 158/158 84/94 90/100 77/86 160/160
MED
NONE — — 34 50 34 153 36 50 36 155
324A 4.9/6.5 13.6/15.6 34/34 50/50 34/34 153/153 36/36 50/50 36/36 155/155
326A 7.9/10.5 21.9/25.3 41/45 50/50 37/41 153/153 43/47 50/50 39/43 155/155
328A 12.0/16.0 33.4/38.5 55/61 60/70 50/56 153/153 57/64 60/70 52/58 155/155
331A 15.8/21.0 43.8/50.5 68/76 70/80 62/70 153/153 70/79 80/80 64/72 155/155
332A 18.4/24.5 51.1/58.9 77/87 80/90 71/80 153/153 80/89 80/90 73/82 155/155
HIGH
NONE — — 35 50 35 154 37 50 37 156
324A 4.9/6.5 13.6/15.6 35/35 50/50 35/35 154/154 37/37 50/50 37/37 156/156
326A 7.9/10.5 21.9/25.3 42/46 50/50 38/42 154/154 44/49 50/50 40/44 156/156
328A 12.0/16.0 33.4/38.5 56/63 60/70 51/57 154/154 59/65 60/70 54/59 156/156
331A 15.8/21.0 43.8/50.5 69/78 70/80 63/71 154/154 72/80 80/80 66/73 156/156
332A 18.4/24.5 51.1/58.9 78/88 80/90 72/81 154/154 81/91 90/100 74/83 156/156
460-3-60
STD
NONE — — 16 20 16 73 17 25 17 74
333A 6.0 7.2 16 20 16 73 17 25 17 74
335A 11.5 13.8 23 25 21 73 24 25 22 74
336A 14.0 16.8 27 30 24 73 28 30 25 74
337A 21.5 25.9 38 40 35 73 39 40 36 74
338A 24.0 28.9 42 45 38 73 43 45 39 74
MED
NONE — — 17 20 16 74 18 25 17 75
333A 6.0 7.2 17 20 16 74 18 25 17 75
335A 11.5 13.8 24 25 21 74 25 25 23 75
336A 14.0 16.8 27 30 25 74 29 30 26 75
337A 21.5 25.9 39 40 35 74 40 40 36 75
338A 24.0 28.9 43 45 39 74 44 45 40 75
HIGH
NONE — — 17 25 17 74 18 25 18 75
333A 6.0 7.2 17 25 17 74 18 25 18 75
335A 11.5 13.8 24 25 22 74 26 30 23 75
336A 14.0 16.8 28 30 25 74 29 30 27 75
337A 21.5 25.9 39 40 36 74 41 45 37 75
338A 24.0 28.9 43 45 39 74 44 45 40 75
575-3-60
STD
NONE — — 13 15 12 62 15 20 14 64
340A 15.0 14.4 23 25 21 62 25 30 23 64
341A 21.0 20.2 30 30 27 62 33 35 30 64
MED
NONE — — 13 15 13 62 15 20 15 64
340A 15.0 14.4 23 25 21 62 26 30 23 64
341A 21.0 20.2 31 35 28 62 33 35 30 64
HIGH
NONE — — 13 15 13 63 15 20 15 65
340A 15.0 14.4 24 25 22 63 26 30 24 65
341A 21.0 20.2 31 35 28 63 34 35 30 65
Electrical data (cont)
