582K 3 TO 5 TON GAS HEAT DATA — 1 PHASE UNITS
LEGEND
* Base unit operating weight does not include weight of options.
582K UNIT 582K*04 582K*05 582K*06
GAS CONNECTION
No. of Gas Valves 1
Natural Gas Supply Line Pressure (in. wg)/(psig) 4-13 / 0.18-0.47
Liquid Propane Supply Line Pressure (in. wg)/(psig) 11-13 / 0.40-0.47
HEAT ANTICIPATOR SETTING (AMPS)
First Stage 0.14
Second Stage 0.14
NATURAL GAS HEAT
LOW
No. of Stages / No. of Burners (total) 1 / 2
Connection Size
1
/
2
-in. NPT
Rollout Switch Opens / Closes (°F) 195 / 115
Temperature Rise (°F) 25-55 20-55 15-55
MEDIUM
No. of Stages / No. of Burners (total) 1 / 3
Connection Size
1
/
2
-in. NPT
Rollout Switch Opens / Closes (°F) 195 / 115
Temperature Rise (°F) 45-85 30-65 25-65
HIGH
No. of Stages / No. of Burners (total) — 1 / 3
Connection Size —
1
/
2
-in. NPT
Rollout Switch Opens / Closes (°F) — 195 / 115
Temperature Rise (°F) — 45-80 35-80
LIQUID PROPANE HEAT
LOW
No. of Stages / No. of Burners (total) 1 / 2
Connection Size
1
/
2
-in. NPT
Rollout Switch Opens / Closes (°F) 195 / 115
Temperature Rise (°F) 25-55 20-55 15-55
MEDIUM
No. of Stages / No. of Burners (total) 1 / 3
Connection Size
1
/
2
-in. NPT
Rollout Switch Opens / Closes (°F) 195 / 115
Temperature Rise (°F) 45-85 30-65 25-65
HIGH
No. of Stages / No. of Burners (total) — 1 / 3
Connection Size —
1
/
2
-in. NPT
Rollout Switch Opens / Closes (°F) — 195 / 115
Temperature Rise (°F) — 45-80 35-80
LOW NOx GAS HEAT
LOW
No. of Stages / No. of Burners (total) 1 / 2
Connection Size
1
/
2
-in. NPT
Rollout Switch Opens / Closes (°F) 195 / 115
Temperature Rise (°F) 20-50 15-50
BHP — Break Horsepower
FPI — Fins Per Inch
OA — Outdoor Air
RA — Return Air
