34
LEGEND
582/559K 07 — UNIT WITH PERFECT HUMIDITY™ SYSTEM IN SUBCOOLING MODE — COOLING CAPACITIES
TEMP (F)
AIR ENTERING
CONDENSER (Edb)
AIR ENTERING EVAPORATOR — SCFM/BF
1800 / 0.06 2400 / 0.08 3000 / 0.10
Air Entering Evaporator — Ewb (F)
72 67 62 72 67 62 72 67 62
75
TC 73.7 66.6 60.2 78.4 71.0 64.4 81.3 73.7 67.4
SHC 32.8 40.5 48.3 37.8 47.8 57.7 42.1 54.3 65.7
kW 4.05 4.01 3.97 4.00 4.04 4.08 4.09 4.05 4.02
85
TC 69.5 62.8 56.8 73.8 67.0 60.7 76.8 69.6 63.6
SHC 28.8 36.9 45.0 33.4 43.9 54.2 37.7 50.4 62.0
kW 4.46 4.43 4.39 4.42 4.45 4.48 4.51 4.47 4.43
95
TC 65.1 58.8 53.0 69.3 62.7 56.8 71.9 65.1 59.5
SHC 24.7 33.1 41.5 29.1 39.9 50.5 33.2 46.1 58.1
kW 4.92 4.89 4.86 4.88 4.91 4.95 4.96 4.92 4.90
105
TC 60.4 54.4 49.0 64.2 58.0 52.5 66.7 60.3 55.0
SHC 20.3 29.1 37.9 24.4 35.6 46.6 28.3 41.8 53.9
kW 5.43 5.40 5.37 5.39 5.42 5.45 5.47 5.43 5.41
115
TC 55.3 49.7 44.7 58.8 53.1 47.9 61.0 55.1 50.1
SHC 15.7 24.9 34.0 19.5 31.2 42.5 23.2 37.1 50.0
kW 5.99 5.96 5.93 5.95 5.98 6.01 6.02 5.99 5.97
125
TC 49.8 44.7 40.1 53.0 47.6 43.0 55.0 49.5 45.0
SHC 10.7 20.5 30.0 14.3 26.4 38.1 17.8 32.1 45.0
kW 6.59 6.57 6.55 6.56 6.59 6.61 6.62 6.60 6.58
582/559K 07 — UNIT WITH PERFECT HUMIDITY SYSTEM IN HOT GAS REHEAT MODE — COOLING CAPACITIES
TEMP (F)
AIR ENTERING
CONDENSER (Edb)
AIR ENTERING EVAPORATOR — Ewb (F)
75 Dry Bulb
62.5 Wet Bulb
(50% Relative)
75 Dry Bulb
64 Wet Bulb
(56% Relative)
75 Dry Bulb
65.3 Wet Bulb
(60% Relative)
Air Entering Evaporator — Cfm
1800 2400 3000 1800 2400 3000 1800 2400 3000
80
TC 14.02 15.01 15.61 14.70 15.71 16.33 15.30 16.34 16.97
SHC -0.84 1.73 4.56 -2.95 -0.90 1.45 -4.78 -3.17 -1.24
kW 4.15 4.16 4.17 4.17 4.18 4.18 4.18 4.19 4.20
75
TC 15.10 16.17 16.79 15.82 16.89 17.52 16.45 17.54 18.19
SHC 0.25 2.88 5.72 -1.81 0.29 2.64 -3.59 -1.95 -0.02
kW 3.96 3.97 3.98 3.98 3.99 4.00 4.00 4.01 4.01
70
TC 15.37 16.68 17.44 16.19 17.39 18.18 17.08 18.37 19.28
SHC 0.50 3.39 6.36 -1.44 0.78 3.30 -2.94 -1.07 1.12
kW 3.97 3.93 3.91 3.96 3.95 3.93 3.92 3.89 3.87
60
TC 16.00 16.95 17.50 16.64 17.59 18.16 18.27 18.17 19.09
SHC 1.11 3.63 6.39 -1.04 0.94 3.23 -1.92 -1.39 0.84
kW 3.95 3.99 4.01 3.99 4.02 4.04 4.09 4.05 4.01
50
TC 16.10 16.93 17.42 16.68 17.50 18.57 17.19 18.60 19.12
SHC 1.18 3.58 6.29 -1.05 0.83 3.63 -2.98 -0.98 0.84
kW 4.03 4.08 4.11 4.07 4.12 4.05 4.12 4.06 4.09
40
TC 16.83 17.62 18.25 17.38 18.17 18.61 17.86 19.42 19.92
SHC 1.89 4.25 5.84 -0.36 1.47 3.65 -2.32 -0.17 1.62
kW 3.96 4.02 4.08 4.01 4.08 4.11 4.06 4.00 4.03
Ewb — Entering wet bulb
kW — Compressor Power Input
SCFM/BF— Standard Cubic Feet per Minute/Bypass Factor
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
Performance data (cont)
