LEGEND NOTE: See minimum-maximum airflow ratings on page 7.
582/559K LOW STAGE COOLING CAPACITIES
582/559K 07
AMBIENT TEMPERATURE (F)
85 95 105 115
EAT (db) EAT (db) EAT (db) EAT (db)
75 80 85 75 80 85 75 80 85 75 80 85
1200
Cfm
EAT
(wb)
58
TC 44.2 44.2 50.4 41.6 41.6 47.5 38.8 38.8 44.4 35.7 35.7 41.0
SHC 38.0 44.2 50.4 35.7 41.6 47.5 33.1 38.8 44.4 30.3 35.7 41.0
62
TC 47.6 47.6 47.6 44.3 44.3 45.1 40.8 40.8 43.0 37.0 37.0 40.7
SHC 34.0 40.5 47.0 32.0 38.5 45.1 29.9 36.5 43.0 27.7 34.2 40.7
67
TC 53.1 53.1 53.1 49.7 49.7 49.7 45.9 45.9 45.9 41.9 41.9 41.9
SHC 28.1 34.7 41.2 26.2 32.7 39.2 24.1 30.6 37.2 21.9 28.5 35.0
72
TC 59.0 59.0 59.0 55.4 55.4 55.4 51.5 51.5 51.5 47.2 47.2 47.2
SHC 22.1 28.6 35.2 20.2 26.7 33.3 18.1 24.7 31.2 16.0 22.6 29.1
76
TC — 64.2 64.2 — 60.4 60.4 — 56.3 56.3 — 51.8 51.8
SHC — 23.7 30.3 — 21.8 28.4 — 19.8 26.4 — 17.8 24.4
1400
Cfm
EAT
(wb)
58
TC 47.4 47.4 53.9 44.6 44.6 50.9 41.6 41.6 47.6 38.3 38.3 43.9
SHC 40.8 47.4 53.9 38.3 44.6 50.9 35.6 41.6 47.6 32.6 38.3 43.9
62
TC 49.5 49.5 52.3 46.1 46.1 50.3 42.4 42.4 48.1 38.5 38.5 45.7
SHC 37.2 44.8 52.3 35.2 42.7 50.3 33.0 40.6 48.1 30.7 38.2 45.7
67
TC 55.0 55.0 55.0 51.5 51.5 51.5 47.5 47.5 47.5 43.3 43.3 43.3
SHC 30.2 37.8 45.4 28.3 35.8 43.4 26.1 33.7 41.3 23.9 31.5 39.1
72
TC 61.1 61.1 61.1 57.3 57.3 57.3 53.1 53.1 53.1 48.7 48.7 48.7
SHC 23.1 30.8 38.4 21.2 28.8 36.4 19.1 26.7 34.3 16.9 24.6 32.2
76
TC — 66.4 66.4 — 62.4 62.4 — 58.1 58.1 — 53.4 53.4
SHC — 25.0 32.7 — 23.1 30.8 — 21.1 28.8 — 18.9 26.6
1600
Cfm
EAT
(wb)
58
TC 50.0 50.0 56.8 47.1 47.1 53.6 43.9 43.9 50.1 40.4 40.4 46.3
SHC 43.1 50.0 56.8 40.5 47.1 53.6 37.6 43.9 50.1 34.5 40.4 46.3
62
TC 51.0 51.0 57.3 47.5 47.5 55.2 43.9 43.9 52.3 40.5 40.5 48.4
SHC 40.2 48.8 57.3 38.1 46.6 55.2 35.6 43.9 52.3 32.6 40.5 48.4
67
TC 56.5 56.5 56.5 52.8 52.8 52.8 48.7 48.7 48.7 44.3 44.3 44.3
SHC 32.2 40.9 49.5 30.2 38.8 47.5 28.1 36.7 45.3 25.8 34.5 43.1
72
TC 62.6 62.6 62.6 58.7 58.7 58.7 54.4 54.4 54.4 49.8 49.8 49.8
SHC 24.1 32.7 41.4 22.1 30.7 39.4 20.0 28.6 37.3 17.8 26.5 35.1
76
TC — 68.0 68.0 — 63.9 63.9 — 59.5 59.5 — 54.7 54.7
SHC — 26.2 35.0 — 24.2 33.0 — 22.2 30.9 — 20.0 28.8
1800
Cfm
EAT
(wb)
58
TC 52.2 52.2 59.3 49.2 49.2 56.0 45.8 45.8 52.3 42.2 42.2 48.4
SHC 45.1 52.2 59.3 42.4 49.2 56.0 39.3 45.8 52.3 36.1 42.2 48.4
62
TC 52.3 52.3 61.8 49.2 49.2 58.3 45.9 45.9 54.5 42.3 42.3 50.4
SHC 42.8 52.3 61.8 40.2 49.2 58.3 37.2 45.9 54.5 34.1 42.3 50.4
67
TC 57.6 57.6 57.6 53.8 53.8 53.8 49.6 49.6 49.6 45.2 45.2 47.0
SHC 34.1 43.8 53.5 32.1 41.8 51.4 29.9 39.6 49.3 27.6 37.3 47.0
72
TC 63.8 63.8 63.8 59.8 59.8 59.8 55.4 55.4 55.4 50.7 50.7 50.7
SHC 24.9 34.6 44.4 22.9 32.6 42.3 20.8 30.5 40.2 18.6 28.3 38.0
76
TC — 69.4 69.4 — 65.2 65.2 — 60.6 60.6 — — —
SHC — 27.3 37.1 — 25.3 35.1 — 23.2 33.0 — — —
2000
Cfm
EAT
(wb)
58
TC 54.1 54.1 61.5 51.0 51.0 58.0 47.5 47.5 54.2 43.8 43.8 50.1
SHC 46.8 54.1 61.5 43.9 51.0 58.0 40.8 47.5 54.2 37.4 43.8 50.1
62
TC 54.2 54.2 64.0 51.0 51.0 60.4 47.6 47.6 56.5 43.8 43.8 52.2
SHC 44.4 54.2 64.0 41.7 51.0 60.4 38.6 47.6 56.5 35.4 43.8 52.2
67
TC 58.6 58.6 58.6 54.7 54.7 55.3 50.4 50.4 53.0 45.9 45.9 50.7
SHC 35.9 46.6 57.3 33.8 44.6 55.3 31.7 42.3 53.0 29.4 40.0 50.7
72
TC 64.8 64.8 64.8 60.7 60.7 60.7 56.1 56.1 56.1 51.4 51.4 51.4
SHC 25.7 36.5 47.2 23.7 34.4 45.2 21.5 32.3 43.0 19.3 30.0 40.8
76
TC —70.570.5—66.266.2——————
SHC —28.339.2—26.337.1——————
— — Do Not Operate
Cfm — Cubic Feet Per Minute (Supply Air)
EAT (db) — Entering Air Temperature (dry bulb)
EAT (wb) — Entering Air Temperature (wet bulb)
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
