7
SOUND RATINGS TABLE
LEGEND
NOTES:
1. Outdoor sound data is measured in accordance with AHRI.
2. Measurements are expressed in terms of sound power. Do not
compare these values to sound pressure values because sound
pressure depends on specific environmental factors which nor
-
mally do not match individual applications. Sound power values
are independent of the environment and therefore more accurate.
3. A-weighted sound ratings filter out very high and very low frequen-
cies, to better approximate the response of “average” human ear.
A-weighted measurements for Bryant units are taken in accor-
dance with AHRI.
MINIMUM - MAXIMUM AIRFLOW RATINGS (CFM) — NATURAL GAS AND PROPANE
*Heating rating values are identical for aluminum heat exchangers and
stainless steel heat exchangers.
MINIMUM - MAXIMUM AIRFLOW RATINGS (CFM) — COOLING UNITS AND ACCESSORY ELECTRIC HEAT
*Electric heat modules are available as field-installed accessories for
559K units.
582/559K
UNIT
COOLING
STAGES
OUTDOOR SOUND (DB) AT 60 Hz
A-WEIGHTED 63 125 250 500 1000 2000 4000 8000
04 1 79 85.6 84.7 80.5 76.0 72.4 68.0 62.8 59.3
05 1 79 85.6 84.7 80.5 76.0 72.4 68.0 62.8 59.3
06 1 79 85.6 84.7 80.5 76.0 72.4 68.0 62.8 59.3
07 2 79 85.6 84.7 80.5 76.0 72.4 68.0 62.8 59.3
dB — Decibel
VOLTAGE UNIT
HEAT
LEVEL
COOLING HEATING*
MINIMUM
AIRFLOW
CFM
MINIMUM
2-SPEED
AIRFLOW
(LOW SPEED)
MINIMUM
2-SPEED
AIRFLOW
(HIGH SPEED)
MAXIMUM
AIRFLOW
CFM
MINIMUM
AIRFLOW
CFM
MAXIMUM
ARIFLOW
CFM
1 PHASE
582K 04
LOW
900 N/A N/A 1500
890 1950
MED 800 1520
HIGH N/A N/A
582K 05
LOW
1200 N/A N/A 2000
890 2440
MED 1050 2280
HIGH 1220 2170
582K 06
LOW
1500 N/A N/A 2500
890 3250
MED 1050 2730
HIGH 1220 2790
3 PHASE
582K 04
LOW
900 N/A N/A 1500
910 2010
MED 960 1160
HIGH N/A N/A
582K 05
LOW
1200 N/A N/A 2000
910 2010
MED 1250 2330
HIGH 1390 2220
582K 06
LOW
1500 N/A N/A 2500
910 2510
MED 1250 2720
HIGH 1390 2780
582K 07
LOW
1800 1200 1800 3000
910 3350
MED 1250 3260
HIGH 1390 3170
UNIT
COOLING ELECTRIC HEAT*
MIMIMUM
AIRFLOW CFM
MINIMUM
2-SPEED AIRFLOW
(LOW SPEED)
MINIMUM
2-SPEED
AIRFLOW
(HIGH SPEED)
MAXIMUM
AIRFLOW CFM
MINIMUM
AIRFLOW CFM
MAXIMUM
AIRFLOW CFM
559K 04 900 N/A N/A 1500 900 1500
559K 05 1200 N/A N/A 2000 1200 2000
559K 06 1500 N/A N/A 2500 1500 2500
559K 07 1800 1200 1800 3000 1800 3000
Capacity ratings (cont)
