LEGEND NOTE: See minimum-maximum airflow ratings on page 7.
582/559K 07 HIGH STAGE COOLING CAPACITIES
582/559K 07
AMBIENT TEMPERATURE (F)
85 95 105 115
EAT (db) EAT (db) EAT (db) EAT (db)
75 80 85 75 80 85 75 80 85 75 80 85
1800
Cfm
EAT
(wb)
58
TC 63.8 63.8 72.2 61.1 61.1 69.1 58.1 58.1 65.8 54.9 54.9 62.3
SHC 55.5 63.8 72.2 53.0 61.1 69.1 50.4 58.1 65.8 47.6 54.9 62.3
62
TC 67.2 67.2 68.3 63.7 63.7 66.4 60.0 60.0 64.4 56.2 56.2 62.3
SHC 49.9 59.1 68.3 48.1 57.3 66.4 46.1 55.3 64.4 44.1 53.2 62.3
67
TC 73.2 73.2 73.2 69.5 69.5 69.5 65.5 65.5 65.5 61.4 61.4 61.4
SHC 40.8 50.0 59.2 39.0 48.2 57.4 37.1 46.3 55.6 35.2 44.4 53.6
72
TC 79.7 79.7 79.7 75.7 75.7 75.7 71.5 71.5 71.5 67.1 67.1 67.1
SHC 31.4 40.7 50.0 29.7 39.0 48.3 27.9 37.2 46.4 26.1 35.3 44.5
76
TC — 85.3 85.3 — 81.0 81.0 — 76.6 76.6 — 72.0 72.0
SHC — 33.3 43.1 — 31.6 41.3 — 29.8 39.5 — 28 37.6
2100
Cfm
EAT
(wb)
58
TC 67.1 67.1 75.9 64.1 64.1 72.5 60.9 60.9 69.0 57.6 57.6 65.2
SHC 58.3 67.1 75.9 55.7 64.1 72.5 52.8 60.9 69.0 49.9 57.6 65.2
62
TC 69.0 69.0 74.7 65.4 65.4 72.6 61.6 61.6 70.4 57.7 57.7 68.0
SHC 53.6 64.1 74.7 51.7 62.2 72.6 49.6 60.0 70.4 47.4 57.7 68.0
67
TC 75.0 75.0 75.0 71.2 71.2 71.2 67.0 67.0 67.0 62.7 62.7 62.7
SHC 43.2 53.8 64.4 41.4 52.0 62.6 39.5 50.1 60.7 37.6 48.2 58.7
72
TC 81.6 81.6 81.6 77.5 77.5 77.5 73.1 73.1 73.1 68.5 68.5 68.5
SHC 32.5 43.2 53.8 30.7 41.4 52.0 28.9 39.5 50.1 27.1 37.6 48.2
76
TC — 87.2 87.2 — 82.8 82.8 — 78.2 78.2 — 73.5 73.5
SHC — 34.6 45.7 — 32.9 43.9 — 31.1 42.0 — 29.2 40.1
2400
Cfm
EAT
(wb)
58
TC 69.7 69.7 78.8 66.6 66.6 75.3 63.2 63.2 71.6 59.7 59.7 67.6
SHC 60.6 69.7 78.8 57.8 66.6 75.3 54.9 63.2 71.6 51.7 59.7 67.6
62
TC 70.5 70.5 80.4 66.9 66.9 78.0 63.3 63.3 74.4 59.7 59.7 70.3
SHC 57.0 68.7 80.4 54.9 66.5 78.0 52.1 63.3 74.4 49.1 59.7 70.3
67
TC 76.4 76.4 76.4 72.4 72.4 72.4 68.2 68.2 68.2 63.8 63.8 63.8
SHC 45.5 57.5 69.4 43.7 55.6 67.5 41.8 53.7 65.6 39.8 51.7 63.6
72
TC 83.1 83.1 83.1 78.8 78.8 78.8 74.2 74.2 74.2 69.6 69.6 69.6
SHC 33.5 45.5 57.4 31.7 43.6 55.6 29.8 41.8 53.7 28.0 39.9 51.7
76
TC — 88.8 88.8 — 84.2 84.2 — 79.5 79.5 — 74.6 74.6
SHC — 35.9 48.2 — 34.1 46.4 — 32.3 44.5 — 30.4 42.5
2700
Cfm
EAT
(wb)
58
TC 71.9 71.9 81.3 68.7 68.7 77.7 65.1 65.1 73.7 61.5 61.5 69.7
SHC 62.5 71.9 81.3 59.6 68.7 77.7 56.5 65.1 73.7 53.3 61.5 69.7
62
TC 72.0 72.0 84.5 68.7 68.7 80.7 65.2 65.2 76.6 61.5 61.5 72.4
SHC 59.5 72.0 84.5 56.7 68.7 80.7 53.7 65.2 76.6 50.6 61.5 72.4
67
TC 77.5 77.5 77.5 73.4 73.4 73.4 69.0 69.0 70.3 64.5 64.5 68.3
SHC 47.7 61.0 74.2 45.9 59.1 72.3 43.9 57.1 70.3 41.9 55.1 68.3
72
TC 84.2 84.2 84.2 79.8 79.8 79.8 75.2 75.2 75.2 70.4 70.4 70.4
SHC 34.4 47.6 60.9 32.6 45.8 59.0 30.7 43.9 57.1 28.8 42.0 55.1
76
TC — 90.0 90.0 — 85.3 85.3 — 80.5 80.5 — 75.5 75.5
SHC — 37.0 50.6 — 35.2 48.7 — 33.4 46.8 — 31.5 44.8
3000
Cfm
EAT
(wb)
58
TC 73.8 73.8 83.4 70.4 70.4 79.6 66.8 66.8 75.6 63.0 63.0 71.3
SHC 64.2 73.8 83.4 61.2 70.4 79.6 58.0 66.8 75.6 54.6 63.0 71.3
62
TC 73.8 73.8 86.6 70.4 70.4 82.7 66.8 66.8 78.5 63.0 63.0 74.1
SHC 61.0 73.8 86.6 58.2 70.4 82.7 55.1 66.8 78.5 51.9 63.0 74.1
67
TC 78.4 78.4 78.9 74.2 74.2 76.9 69.7 69.7 74.8 65.2 65.2 72.6
SHC 49.8 64.3 78.9 47.9 62.4 76.9 46.0 60.4 74.8 43.9 58.3 72.6
72
TC 85.1 85.1 85.1 80.6 80.6 80.6 75.9 75.9 75.9 71.1 71.1 71.1
SHC 35.2 49.7 64.3 33.4 47.9 62.4 31.5 46.0 60.4 29.7 44.0 58.4
76
TC — 91.0 91.0 — 86.2 86.2 — 81.3 81.3 — 76.3 76.3
SHC — 38.1 52.9 — 36.3 51.0 — 34.5 49.0 — 32.5 47.0
— — Do Not Operate
Cfm — Cubic Feet Per Minute (Supply Air)
EAT (db) — Entering Air Temperature (dry bulb)
EAT (wb) — Entering Air Temperature (wet bulb)
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
