582/559K 06 — UNIT WITH PERFECT HUMIDITY™ SYSTEM IN SUBCOOLING MODE — COOLING CAPACITIES
TEMP (F)
AIR ENTERING
CONDENSER (Edb)
AIR ENTERING EVAPORATOR — SCFM/BF
1500 / 0.01 2000 / 0.02 2500 / 0.03
Air Entering Evaporator — Ewb (F)
72 67 62 72 67 62 72 67 62
75
TC 65.6 59.0 53.7 69.6 63.1 57.4 72.0 65.6 60.4
SHC 25.3 33.5 42.2 29.9 40.9 51.6 34.3 47.6 60.0
kW 3.11 3.06 3.03 3.05 3.09 3.16 3.16 3.11 3.07
85
TC 61.1 55.4 50.2 65.0 58.9 53.7 66.8 61.0 56.4
SHC 21.1 30.0 38.8 25.6 36.9 48.0 29.3 43.3 56.0
kW 3.47 3.43 3.39 3.42 3.46 3.51 3.52 3.48 3.44
95
TC 56.7 51.2 46.4 60.1 54.5 49.6 62.2 56.5 52.1
SHC 16.9 26.1 35.2 21.0 32.7 44.2 25.0 39.1 52.1
kW 3.89 3.85 3.80 3.83 3.88 3.93 3.95 3.90 3.86
105
TC 51.8 46.6 42.0 54.3 49.0 44.4 56.9 51.1 46.9
SHC 12.3 21.7 31.1 15.5 27.5 39.3 20.0 34.0 46.9
kW 4.36 4.31 4.26 4.29 4.33 4.38 4.42 4.36 4.32
115
TC 46.5 41.9 37.8 49.1 44.3 40.2 50.8 46.2 42.5
SHC 7.3 17.3 27.2 10.7 23.2 35.4 14.4 29.4 42.5
kW 4.88 4.83 4.78 4.81 4.86 4.91 4.93 4.88 4.84
125
TC 40.8 36.7 33.1 43.1 38.9 35.1 44.9 40.5 37.3
SHC 2.0 12.5 22.8 5.2 18.2 30.5 8.9 24.2 37.3
kW 5.44 5.39 5.35 5.37 5.42 5.47 5.49 5.44 5.40
582/559K 06 — UNIT WITH PERFECT HUMIDITY SYSTEM IN HOT GAS REHEAT MODE — COOLING CAPACITIES
TEMP (F)
AIR ENTERING
CONDENSER (Edb)
AIR ENTERING EVAPORATOR — Ewb (F)
75 Dry Bulb
62.5 Wet Bulb
(50% Relative)
75 Dry Bulb
64 Wet Bulb
(56% Relative)
75 Dry Bulb
65.3 Wet Bulb
(60% Relative)
Air Entering Evaporator — Cfm
1500 2000 2500 1500 2000 2500 1500 2000 2500
80
TC 13.19 12.95 12.70 14.56 14.30 14.00 15.70 15.44 15.05
SHC -2.38 -1.55 -0.65 -4.75 -4.25 -3.69 -6.74 -6.49 -6.21
kW 3.15 3.16 3.16 3.19 3.20 3.20 3.22 3.23 3.23
75
TC 16.14 15.95 15.71 17.36 17.20 16.84 18.30 18.20 17.81
SHC 0.44 1.23 2.03 -1.92 -1.36 -0.96 -3.90 -3.50 -3.31
kW 3.04 3.05 3.06 3.07 3.08 3.09 3.10 3.12 3.12
70
TC 18.90 18.68 18.52 19.97 19.85 19.50 20.86 20.62 20.17
SHC 3.13 3.80 4.51 0.85 1.39 1.70 -0.97 -0.69 -0.63
kW 2.92 2.93 2.95 2.96 2.97 2.98 2.98 2.99 3.00
60
TC 23.71 23.48 23.16 24.05 23.98 23.52 24.79 24.47 26.99
SHC 8.11 8.63 8.88 5.97 6.46 6.58 4.65 4.87 5.94
kW 3.17 3.23 3.15 3.21 3.26 3.18 3.23 3.12 3.10
50
TC 21.91 16.69 16.62 16.81 16.98 16.92 17.08 17.24 17.17
SHC 11.51 10.04 9.64 9.77 9.43 8.95 9.30 8.88 8.35
kW 3.01 3.07 3.11 3.04 3.10 3.15 3.07 3.14 3.18
40
TC 21.91 16.69 16.62 16.81 16.98 16.92 17.08 17.24 17.17
SHC 11.51 10.04 9.64 9.77 9.43 8.95 9.30 8.88 8.35
kW 3.39 3.32 3.24 3.14 3.23 3.15 3.18 3.27 3.08
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW — Compressor Power Input
SCFM/BF— Standard Cubic Feet per Minute/Bypass Factor
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
