LEGEND NOTE: See minimum-maximum airflow ratings on page 7.
582/559K 06 SINGLE STAGE COOLING CAPACITIES
582/559K 06
AMBIENT TEMPERATURE (F)
85 95 105 115
EAT (db) EAT (db) EAT (db) EAT (db)
75 80 85 75 80 85 75 80 85 75 80 85
1500
Cfm
EAT
(wb)
58
TC 52.2 52.2 58.7 49.3 49.3 55.4 46.0 46.0 51.7 42.5 42.5 47.7
SHC 45.7 52.2 58.7 43.2 49.3 55.4 40.3 46.0 51.7 37.2 42.5 47.7
62
TC 55.2 55.2 56.6 51.3 51.3 54.6 47.1 47.1 52.4 42.6 42.6 49.7
SHC 41.9 49.2 56.6 40.0 47.3 54.6 37.9 45.2 52.4 35.5 42.6 49.7
67
TC 61.0 61.0 61.0 57.5 57.5 57.5 53.2 53.2 53.2 48.4 48.4 48.4
SHC 34.7 41.9 49.1 33.3 40.6 48.0 31.5 38.9 46.2 29.5 36.8 44.2
72
TC 64.4 64.4 64.4 62.9 62.9 62.9 59.4 59.4 59.4 55.1 55.1 55.1
SHC 26.4 33.4 40.5 25.8 33.1 40.3 24.5 31.8 39.1 22.8 30.2 37.6
76
TC — 66.0 66.0 — 65.1 65.1 — 63.0 63.0 — 59.5 59.5
SHC — 26.9 35.1 — 26.5 34.8 — 25.8 34.0 — 24.4 32.4
1750
Cfm
EAT
(wb)
58
TC 54.8 54.8 61.7 51.6 51.6 58.1 48.2 48.2 54.3 44.5 44.5 50.1
SHC 47.9 54.8 61.7 45.1 51.6 58.1 42.1 48.2 54.3 38.9 44.5 50.1
62
TC 56.5 56.5 60.9 52.7 52.7 59.0 48.4 48.4 56.5 44.6 44.6 52.1
SHC 44.3 52.6 60.9 42.4 50.7 59.0 40.2 48.4 56.5 37.0 44.6 52.1
67
TC 62.0 62.0 62.0 58.7 58.7 58.7 54.4 54.4 54.4 49.4 49.4 49.4
SHC 35.7 43.7 51.7 34.6 42.9 51.2 32.9 41.3 49.7 30.9 39.3 47.8
72
TC 64.6 64.6 64.6 63.4 63.4 63.4 60.3 60.3 60.3 56.1 56.1 56.1
SHC 26.2 33.8 41.5 25.8 33.8 41.8 24.6 32.9 41.1 23.1 31.4 39.8
76
TC — 65.9 65.9 — 64.8 64.8 — 63.3 63.3 — 59.9 59.9
SHC — 27.2 36.8 — 26.7 36.3 — 26.0 35.1 — 24.7 33.5
2000
Cfm
EAT
(wb)
58
TC 56.6 56.6 63.8 53.5 53.5 60.3 49.9 49.9 56.3 46.1 46.1 52.0
SHC 49.4 56.6 63.8 46.7 53.5 60.3 43.6 49.9 56.3 40.2 46.1 52.0
62
TC 57.5 57.5 64.5 53.7 53.7 62.9 50.0 50.0 58.5 46.1 46.1 54.0
SHC 46.2 55.3 64.5 44.5 53.7 62.9 41.4 50.0 58.5 38.2 46.1 54.0
67
TC 62.1 62.1 62.1 59.3 59.3 59.3 55.0 55.0 55.0 50.0 50.0 51.0
SHC 36.0 44.6 53.3 35.5 44.7 53.9 34.0 43.4 52.8 32.1 41.6 51.0
72
TC 64.3 64.3 64.3 63.4 63.4 63.4 60.6 60.6 60.6 56.5 56.5 56.5
SHC 25.7 34.0 42.2 25.4 34.1 42.7 24.5 33.6 42.6 23.1 32.3 41.6
76
TC — 65.6 65.6 — 64.1 64.1 — 63.1 63.1 — 59.9 59.9
SHC — 27.0 37.5 — 26.4 36.5 — 25.8 35.6 — 24.6 34.3
2250
Cfm
EAT
(wb)
58
TC 57.7 57.7 65.2 54.7 54.7 61.8 51.2 51.2 57.8 47.2 47.2 53.3
SHC 50.2 57.7 65.2 47.6 54.7 61.8 44.5 51.2 57.8 41.0 47.2 53.3
62
TC 57.9 57.9 67.9 54.8 54.8 64.3 51.2 51.2 60.1 47.2 47.2 55.4
SHC 47.9 57.9 67.9 45.3 54.8 64.3 42.3 51.2 60.1 39.0 47.2 55.4
67
TC 61.7 61.7 61.7 59.5 59.5 59.5 55.2 55.2 55.5 50.2 50.2 53.9
SHC 36.0 45.1 54.3 36.1 46.2 56.2 34.8 45.1 55.5 33.0 43.5 53.9
72
TC 63.9 63.9 63.9 62.9 62.9 62.9 60.5 60.5 60.5 56.5 56.5 56.5
SHC 25.1 33.8 42.5 24.9 34.0 43.2 24.2 33.9 43.6 22.8 32.9 43.0
76
TC — 65.0 65.0 — 63.5 63.5 — 62.6 62.6 — 59.5 59.5
SHC — 26.5 37.3 — 25.9 36.4 — 25.4 35.8 — 24.4 34.6
2500
Cfm
EAT
(wb)
58
TC 58.2 58.2 65.9 55.4 55.4 62.7 51.9 51.9 58.8 47.9 47.9 54.3
SHC 50.6 58.2 65.9 48.1 55.4 62.7 45.1 51.9 58.8 41.6 47.9 54.3
62
TC 58.2 58.2 68.5 56.4 56.4 59.5 51.9 51.9 61.1 47.9 47.9 56.4
SHC 48.0 58.2 68.5 42.8 51.1 59.5 42.8 51.9 61.1 39.4 47.9 56.4
67
TC 61.1 61.1 61.1 59.2 59.2 59.2 55.1 55.1 57.7 50.1 50.1 56.3
SHC 35.8 45.5 55.2 36.4 47.2 57.9 35.3 46.5 57.7 33.6 44.9 56.3
72
TC 63.1 63.1 63.1 62.0 62.0 62.0 60.0 60.0 60.0 56.1 56.1 56.1
SHC 24.3 33.4 42.5 24.0 33.6 43.2 23.5 33.9 44.3 22.3 33.1 43.9
76
TC — 64.1 64.1 — 62.7 62.7 — 61.8 61.8 — 58.8 58.8
SHC — 25.8 36.9 — 25.2 36.1 — 24.8 35.7 — 23.8 34.7
— — Do Not Operate
Cfm — Cubic Feet Per Minute (Supply Air)
EAT (db) — Entering Air Temperature (dry bulb)
EAT (wb) — Entering Air Temperature (wet bulb)
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
