29
LEGEND
582/559K 05 — UNIT WITH PERFECT HUMIDITY™ SYSTEM IN SUBCOOLING MODE — COOLING CAPACITIES
TEMP (F)
AIR ENTERING
CONDENSER (Edb)
AIR ENTERING EVAPORATOR — SCFM/BF
1200 / 0.04 1600 / 0.07 2000 / 0.10
Air Entering Evaporator — Ewb (F)
72 67 62 72 67 62 72 67 62
75
TC 49.7 44.9 40.6 52.9 47.8 43.5 54.8 49.8 0.0
SHC 20.8 26.2 31.6 24.0 30.9 37.9 26.8 35.2 0.0
kW 2.50 2.47 2.44 2.46 2.48 2.51 2.53 2.50 0.00
85
TC 46.5 42.0 37.9 49.1 44.7 40.6 51.2 46.5 42.6
SHC 17.8 23.5 29.2 20.5 28.0 35.2 23.5 32.1 40.5
kW 2.81 2.78 2.76 2.78 2.80 2.82 2.84 2.81 2.79
95
TC 43.1 38.9 35.1 45.8 41.5 37.6 47.5 43.1 39.4
SHC 14.6 20.6 26.5 17.5 25.0 32.4 20.1 28.9 37.5
kW 3.16 3.14 3.12 3.13 3.15 3.18 3.19 3.16 3.14
105
TC 39.3 35.3 32.0 41.8 37.7 34.2 43.4 39.1 35.9
SHC 11.1 17.3 23.7 13.8 21.5 29.3 16.3 25.3 34.3
kW 3.56 3.54 3.52 3.54 3.55 3.58 3.59 3.56 3.55
115
TC 35.3 31.8 28.6 37.4 33.7 30.5 39.1 35.3 32.2
SHC 7.5 14.1 20.6 9.7 17.8 25.9 12.3 21.8 30.8
kW 4.02 4.01 4.00 4.00 4.01 4.03 4.04 4.03 4.01
125
TC 31.2 27.9 24.9 33.2 29.8 26.8 34.5 31.0 28.3
SHC 3.7 10.5 17.3 5.9 14.3 22.5 8.1 17.9 27.1
kW 4.54 4.53 4.53 4.53 4.54 4.54 4.55 4.54 4.54
582/559K 05 — UNIT WITH PERFECT HUMIDITY SYSTEM IN HOT GAS REHEAT MODE — COOLING CAPACITIES
TEMP (F)
AIR ENTERING
CONDENSER (Edb)
AIR ENTERING EVAPORATOR — Ewb (F)
75 Dry Bulb
62.5 Wet Bulb
(50% Relative)
75 Dry Bulb
64 Wet Bulb
(56% Relative)
75 Dry Bulb
65.3 Wet Bulb
(60% Relative)
Air Entering Evaporator — Cfm
1200 1600 2000 1200 1600 2000 1200 1600 2000
80
TC 10.55 10.36 10.16 11.65 11.44 11.20 12.56 12.35 12.04
SHC -1.90 -1.24 -0.52 -3.80 -3.40 -2.95 -5.39 -5.19 -4.97
kW 3.15 3.16 3.16 3.19 3.20 3.20 3.22 3.23 3.23
75
TC 12.91 12.76 12.57 13.89 13.76 13.47 14.64 14.56 14.25
SHC 0.35 0.98 1.63 -1.54 -1.09 -0.76 -3.12 -2.80 -2.65
kW 3.04 3.05 3.06 3.07 3.08 3.09 3.10 3.12 3.12
70
TC 15.12 14.94 14.82 15.98 15.88 15.60 16.69 16.50 16.13
SHC 2.51 3.04 3.60 0.68 1.11 1.36 -0.78 -0.55 -0.50
kW 2.92 2.93 2.95 2.96 2.97 2.98 2.98 2.99 3.00
60
TC 18.97 18.79 18.53 19.24 19.18 18.82 19.83 19.58 21.59
SHC 6.49 6.91 7.10 4.77 5.17 5.26 3.72 3.89 4.75
kW 3.17 3.23 3.15 3.21 3.26 3.18 3.23 3.12 3.10
50
TC 17.53 13.35 13.30 13.45 13.58 13.53 13.67 13.79 13.74
SHC 9.21 8.03 7.71 7.82 7.54 7.16 7.44 7.10 6.68
kW 3.01 3.07 3.11 3.04 3.10 3.15 3.07 3.14 3.18
40
TC 17.53 13.35 13.30 13.45 13.58 13.53 13.67 13.79 13.74
SHC 9.21 8.03 7.71 7.82 7.54 7.16 7.44 7.10 6.68
kW 3.39 3.32 3.24 3.14 3.23 3.15 3.18 3.27 3.08
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW — Compressor Power Input
SCFM/BF— Standard Cubic Feet per Minute/Bypass Factor
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
Performance data (cont)
