28
LEGEND NOTE: See minimum-maximum airflow ratings on page 7.
582/559K 05 SINGLE STAGE COOLING CAPACITIES
582/559K 05
AMBIENT TEMPERATURE (F)
85 95 105 115
EAT (db) EAT (db) EAT (db) EAT (db)
75 80 85 75 80 85 75 80 85 75 80 85
1200
Cfm
EAT
(wb)
58
TC 40.5 40.5 44.8 37.5 37.5 43.0 34.5 34.5 39.6 30.9 30.9 35.7
SHC 34.0 39.4 44.8 32.1 37.5 43.0 29.4 34.5 39.6 26.2 30.9 35.7
62
TC 43.9 43.9 43.9 40.4 40.4 41.0 36.4 36.4 38.7 31.9 31.9 36.2
SHC 31.1 37.1 43.1 29.0 35.0 41.0 26.7 32.7 38.7 24.2 30.2 36.2
67
TC 49.3 49.3 49.3 46.1 46.1 46.1 42.3 42.3 42.3 37.8 37.8 37.8
SHC 25.7 31.5 37.4 23.9 29.8 35.6 21.8 27.7 33.6 19.4 25.4 31.4
72
TC 54.7 54.7 54.7 51.5 51.5 51.5 48.0 48.0 48.0 44.0 44.0 44.0
SHC 20.3 25.8 31.2 18.5 24.1 29.7 16.6 22.2 27.9 14.5 20.2 25.9
76
TC — 58.5 58.5 — 55.7 55.7 — 52.3 52.3 — 48.4 48.4
SHC — 21.2 27.8 — 19.4 26.0 — 17.5 24.1 — 15.8 22.4
1400
Cfm
EAT
(wb)
58
TC 43.0 43.0 49.0 40.1 40.1 45.9 37.0 37.0 42.4 33.3 33.3 38.4
SHC 37.0 43.0 49.0 34.4 40.1 45.9 31.5 37.0 42.4 28.2 33.3 38.4
62
TC 45.3 45.3 47.5 41.8 41.8 45.3 37.9 37.9 43.0 33.5 33.5 39.7
SHC 33.6 40.6 47.5 31.5 38.4 45.3 29.2 36.1 43.0 26.4 33.0 39.7
67
TC 50.9 50.9 50.9 47.5 47.5 47.5 43.7 43.7 43.7 39.2 39.2 39.2
SHC 27.2 34.0 40.7 25.4 32.2 39.0 23.3 30.2 37.1 21.1 28.0 34.9
72
TC 56.0 56.0 56.0 52.9 52.9 52.9 49.2 49.2 49.2 45.2 45.2 45.2
SHC 20.8 27.1 33.5 19.0 25.5 32.1 17.1 23.7 30.3 15.0 21.7 28.4
76
TC — 59.8 59.8 — 56.8 56.8 — 53.3 53.3 — 49.3 49.3
SHC — 21.5 29.2 — 20.0 27.7 — 18.3 24.3 — 16.5 22.7
1600
Cfm
EAT
(wb)
58
TC 45.2 45.2 51.5 42.2 42.2 48.3 39.0 39.0 44.7 35.2 35.2 40.6
SHC 38.8 45.2 51.5 36.2 42.2 48.3 33.2 39.0 44.7 29.9 35.2 40.6
62
TC 46.4 46.4 51.4 42.8 42.8 49.0 39.2 39.2 46.0 35.3 35.3 42.4
SHC 35.8 43.6 51.4 33.6 41.3 49.0 31.0 38.5 46.0 28.1 35.3 42.4
67
TC 51.9 51.9 51.9 48.4 48.4 48.4 44.6 44.6 44.6 40.0 40.0 40.0
SHC 28.5 36.1 43.6 26.6 34.3 42.0 24.7 32.5 40.2 22.4 30.2 38.0
72
TC 56.8 56.8 56.8 53.7 53.7 53.7 50.0 50.0 50.0 45.8 45.8 45.8
SHC 21.0 28.2 35.3 19.3 26.7 34.0 17.4 24.9 32.4 15.4 22.9 30.5
76
TC — 60.4 60.4 — 57.4 57.4 — 53.9 53.9 — — —
SHC — 22.0 27.8 — 20.5 27.1 — 18.8 25.8 — — —
1800
Cfm
EAT
(wb)
58
TC 46.8 46.8 53.4 43.9 43.9 50.2 40.5 40.5 46.5 36.8 36.8 42.4
SHC 40.2 46.8 53.4 37.6 43.9 50.2 34.6 40.5 46.5 31.2 36.8 42.4
62
TC 47.3 47.3 54.6 45.5 45.5 48.6 41.0 41.0 47.7 36.8 36.8 44.3
SHC 37.6 46.1 54.6 33.9 41.3 48.6 32.2 39.9 47.7 29.3 36.8 44.3
67
TC 52.5 52.5 52.5 49.0 49.0 49.0 45.1 45.1 45.1 40.5 40.5 40.9
SHC 29.5 37.8 46.2 27.7 36.2 44.7 25.8 34.4 43.0 23.5 32.2 40.9
72
TC 57.3 57.3 57.3 54.1 54.1 54.1 50.4 50.4 50.4 46.2 46.2 46.2
SHC 21.2 29.0 36.9 19.5 27.6 35.7 17.6 25.8 34.1 15.5 23.9 32.3
76
TC — 60.7 60.7 — 57.8 57.8 — 54.2 54.2 — — —
SHC — 22.2 29.5 — 20.7 28.2 — 19.0 26.9 — — —
2000
Cfm
EAT
(wb)
58
TC 48.0 48.0 54.8 45.1 45.1 51.6 41.8 41.8 47.9 38.0 38.0 43.7
SHC 41.3 48.0 54.8 38.6 45.1 51.6 35.6 41.8 47.9 32.2 38.0 43.7
62
TC 48.5 48.5 56.1 46.6 46.6 49.4 41.8 41.8 50.0 38.0 38.0 45.7
SHC 38.6 47.3 56.1 34.5 42.0 49.4 33.5 41.8 50.0 30.2 38.0 45.7
67
TC 52.7 52.7 52.7 49.2 49.2 49.2 45.3 45.3 45.6 40.7 40.7 43.7
SHC 30.3 39.4 48.5 28.6 37.9 47.2 26.7 36.1 45.6 24.5 34.1 43.7
72
TC 57.5 57.5 57.5 54.3 54.3 54.3 50.6 50.6 50.6 46.3 46.3 46.3
SHC 21.1 29.6 38.2 19.4 28.3 37.1 17.6 26.6 35.6 15.6 24.8 33.9
76
TC —60.760.7—57.857.8——————
SHC —22.330.4—20.829.1——————
— — Do Not Operate
Cfm — Cubic Feet Per Minute (Supply Air)
EAT (db) — Entering Air Temperature (dry bulb)
EAT (wb) — Entering Air Temperature (wet bulb)
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
Performance data (cont)
