582/559K 04 — UNIT WITH PERFECT HUMIDITY™ SYSTEM IN SUBCOOLING MODE — COOLING CAPACITIES
TEMP (F)
AIR ENTERING
CONDENSER (Edb)
AIR ENTERING EVAPORATOR — SCFM/BF
900 / 0.01 1200 / 0.02 1500 / 0.04
Air Entering Evaporator — Ewb (F)
72 67 62 72 67 62 72 67 62
75
TC
29.90
31.00 30.90 29.80 32.50 33.30 33.80 30.90 26.70
SHC
14.70
19.40 25.50 24.30 19.80 14.90 13.60 17.70 21.20
kW
2.51
2.49 2.42 2.82 2.74 2.68 3.09 3.01 2.88
85
TC
31.90
27.50 22.70 18.10 23.10 28.40 23.80 18.30 13.20
SHC
10.70
14.20 17.40 13.00 10.00 6.90 2.60 5.50 8.40
kW
3.36
3.23 3.06 3.62 3.41 3.24 3.79 3.58 3.39
95
TC
30.30
31.00 30.90 29.80 32.50 33.30 33.80 30.90 26.70
SHC
14.80
19.40 25.50 24.30 19.80 14.90 13.60 17.70 21.20
kW
2.53
2.49 2.41 2.82 2.74 2.68 3.09 3.01 2.88
105
TC
31.90
27.50 22.70 18.10 23.10 28.40 23.80 18.30 13.20
SHC
10.70
14.20 17.40 13.00 10.00 6.90 2.60 5.50 8.40
kW
3.36
3.23 3.06 3.62 3.41 3.24 3.79 3.58 3.39
115
TC
30.30
31.00 30.90 29.80 32.50 33.30 33.80 30.90 26.70
SHC
14.80
19.40 25.50 24.30 19.80 14.90 13.60 17.70 21.20
kW
2.53
2.49 2.41 2.82 2.74 2.68 3.09 3.01 2.88
125
TC
31.90
27.50 22.70 18.10 23.10 28.40 23.80 18.30 13.2
SHC
10.70
14.20 17.40 0.00 10.00 6.90 2.60 5.50 8.40
kW
3.36
3.23 3.06 3.62 3.41 3.24 3.79 3.58 3.39
582/559K 04 — UNIT WITH PERFECT HUMIDITY SYSTEM IN HOT GAS REHEAT MODE — COOLING CAPACITIES
TEMP (F)
AIR ENTERING
CONDENSER (Edb)
AIR ENTERING EVAPORATOR — Ewb (F)
75 Dry Bulb
62.5 Wet Bulb
(50% Relative)
75 Dry Bulb
64 Wet Bulb
(56% Relative)
75 Dry Bulb
65.3 Wet Bulb
(60% Relative)
Air Entering Evaporator — Cfm
900 1200 1500 900 1200 1500 900 1200 1500
80
TC 9.81 10.50 10.92 10.83 11.58 12.00 11.78 12.50 12.96
SHC 1.41 3.09 4.87 0.60 1.98 3.47 -0.05 1.04 2.25
kW 1.92 1.93 1.94 1.96 1.98 2.00 2.00 2.01 2.02
75
TC 11.71 12.51 13.04 12.67 13.38 13.86 13.44 13.91 14.32
SHC 3.10 4.87 6.70 2.30 3.67 5.03 1.62 2.51 3.51
kW 1.87 1.88 1.88 1.89 1.90 1.91 1.91 1.92 1.93
70
TC 13.37 14.10 14.41 13.94 14.53 14.90 14.42 14.95 15.10
SHC 4.71 6.28 7.52 3.72 4.86 5.88 2.97 4.07 4.47
kW 1.78 1.80 1.82 1.81 1.83 1.84 1.82 1.82 1.86
60
TC 13.95 14.80 14.62 14.47 15.22 15.53 14.66 14.63 15.46
SHC 6.20 8.05 7.61 5.67 6.67 7.68 5.03 5.55 6.30
kW 1.66 1.62 1.70 1.67 1.69 1.68 1.69 1.70 1.71
50
TC 14.26 14.87 15.78 14.65 15.78 16.21 15.01 16.16 16.58
SHC 5.12 6.39 8.04 3.83 5.37 6.38 2.72 4.09 4.93
kW 1.98 2.03 1.94 2.01 1.94 1.97 2.03 1.96 1.99
40
TC 14.16 15.50 15.88 15.28 16.24 16.28 15.62 16.60 17.01
SHC 5.04 6.99 8.14 4.43 5.81 6.44 3.31 4.51 5.34
kW 2.07 1.95 1.99 1.93 1.91 2.02 1.96 1.94 1.97
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW — Compressor Power Input
SCFM/BF— Standard Cubic Feet per Minute/Bypass Factor
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
