LEGEND NOTE: See minimum-maximum airflow ratings on page 7.
582/559K 04 SINGLE STAGE COOLING CAPACITIES
582/559K 04
AMBIENT TEMPERATURE (F)
85 95 105 115
EAT (db) EAT (db) EAT (db) EAT (db)
75 80 85 75 80 85 75 80 85 75 80 85
900
Cfm
EAT
(wb)
58
TC 28.6 28.6 32.5 27.0 27.0 30.7 25.2 25.2 28.6 23.2 23.2 26.4
SHC 24.7 28.6 32.5 23.3 27.0 30.7 21.7 25.2 28.6 20.0 23.2 26.4
62
TC 31.1 31.1 31.1 28.9 28.9 29.8 26.3 26.3 28.6 23.6 23.6 27.2
SHC 22.4 26.6 30.9 21.3 25.6 29.8 20.2 24.4 28.6 18.8 23.0 27.2
67
TC 35.2 35.2 35.2 33.0 33.0 33.0 30.4 30.4 30.4 27.5 27.5 27.5
SHC 18.7 23.0 27.2 17.8 22.0 26.3 16.7 20.9 25.2 15.5 19.8 24.0
72
TC 38.9 38.9 38.9 37.2 37.2 37.2 34.8 34.8 34.8 31.9 31.9 31.9
SHC 14.7 19.0 23.3 14.0 18.3 22.6 13.1 17.3 21.6 12.0 16.3 20.5
76
TC — 41.5 41.5 — 40.0 40.0 — 38.0 38.0 — 35.4 35.4
SHC — 15.6 20.5 — 15.1 20.0 — 14.3 19.1 — 13.3 17.8
1050
Cfm
EAT
(wb)
58
TC 30.5 30.5 34.7 28.8 28.8 32.7 26.9 26.9 30.6 24.8 24.8 28.2
SHC 26.4 30.5 34.7 24.8 28.8 32.7 23.2 26.9 30.6 21.4 24.8 28.2
62
TC 32.4 32.4 33.9 30.0 30.0 32.7 27.4 27.4 31.3 24.8 24.8 29.3
SHC 24.2 29.1 33.9 23.1 27.9 32.7 21.8 26.6 31.3 20.2 24.8 29.3
67
TC 36.5 36.5 36.5 34.2 34.2 34.2 31.5 31.5 31.5 28.5 28.5 28.5
SHC 19.8 24.6 29.4 19.0 23.8 28.7 17.9 22.7 27.6 16.7 21.5 26.4
72
TC 40.0 40.0 40.0 38.3 38.3 38.3 35.9 35.9 35.9 33.0 33.0 33.0
SHC 15.1 19.9 24.7 14.5 19.3 24.1 13.6 18.5 23.3 12.5 17.4 22.3
76
TC — 42.5 42.5 — 40.9 40.9 — 39.0 39.0 — — —
SHC — 16.3 22.0 — 15.7 21.4 — 14.9 20.2 — — —
1200
Cfm
EAT
(wb)
58
TC 32.1 32.1 36.5 30.3 30.3 34.4 28.3 28.3 32.2 26.1 26.1 29.7
SHC 27.8 32.1 36.5 26.2 30.3 34.4 24.4 28.3 32.2 22.5 26.1 29.7
62
TC 33.3 33.3 36.6 30.9 30.9 35.3 28.4 28.4 33.5 26.1 26.1 30.9
SHC 25.8 31.2 36.6 24.6 29.9 35.3 23.2 28.4 33.5 21.3 26.1 30.9
67
TC 37.4 37.4 37.4 35.1 35.1 35.1 32.4 32.4 32.4 29.2 29.2 29.2
SHC 20.7 25.9 31.2 20.0 25.4 30.8 18.9 24.4 29.8 17.7 23.1 28.6
72
TC 40.7 40.7 40.7 39.0 39.0 39.0 36.7 36.7 36.7 33.8 33.8 33.8
SHC 15.4 20.6 25.9 14.8 20.1 25.4 14.0 19.4 24.8 12.9 18.4 23.8
76
TC — 43.2 43.2 — 41.5 41.5 — 39.7 39.7 — — —
SHC — 16.7 23.0 — 16.0 22.1 — 15.3 21.2 — — —
1350
Cfm
EAT
(wb)
58
TC 33.5 33.5 38.1 31.6 31.6 35.9 29.5 29.5 33.5 27.2 27.2 30.9
SHC 28.9 33.5 38.1 27.3 31.6 35.9 25.4 29.5 33.5 23.4 27.2 30.9
62
TC 34.1 34.1 38.9 31.7 31.7 37.5 29.5 29.5 34.9 27.2 27.2 32.2
SHC 27.1 33.0 38.9 25.9 31.7 37.5 24.1 29.5 34.9 22.2 27.2 32.2
67
TC 38.0 38.0 38.0 35.8 35.8 35.8 33.0 33.0 33.0 29.8 29.8 30.6
SHC 21.4 27.1 32.8 20.8 26.8 32.7 19.8 25.9 31.9 18.6 24.6 30.6
72
TC 41.2 41.2 41.2 39.5 39.5 39.5 37.3 37.3 37.3 34.3 34.3 34.3
SHC 15.6 21.3 26.9 15.0 20.7 26.5 14.3 20.2 26.1 13.2 19.2 25.3
76
TC — 43.7 43.7 — 41.9 41.9 — 40.0 40.0 — — —
SHC — 17.0 23.6 — 16.3 22.7 — 15.6 21.9 — — —
1500
Cfm
EAT
(wb)
58
TC 34.5 34.5 39.2 32.7 32.7 37.1 30.5 30.5 34.6 28.1 28.1 31.9
SHC 29.8 34.5 39.2 28.2 32.7 37.1 26.3 30.5 34.6 24.2 28.1 31.9
62
TC 35.1 35.1 39.1 32.7 32.7 38.7 30.5 30.5 36.1 28.1 28.1 33.3
SHC 27.4 33.3 39.1 26.7 32.7 38.7 24.9 30.5 36.1 22.9 28.1 33.3
67
TC 38.4 38.4 38.4 36.3 36.3 36.3 33.4 33.4 33.8 30.1 30.1 32.5
SHC 22.1 28.2 34.3 21.6 28.0 34.4 20.6 27.2 33.8 19.4 26.0 32.5
72
TC 41.6 41.6 41.6 39.8 39.8 39.8 37.7 37.7 37.7 34.7 34.7 34.7
SHC 15.7 21.8 27.8 15.1 21.3 27.4 14.4 20.8 27.2 13.5 20.0 26.5
76
TC — 44.0 44.0 — 42.2 42.2 — 40.2 40.2 — — —
SHC — 17.2 24.1 — 16.5 23.3 — 15.8 22.5 — — —
— — Do Not Operate
Cfm — Cubic Feet Per Minute (Supply Air)
EAT (db) — Entering Air Temperature (dry bulb)
EAT (wb) — Entering Air Temperature (wet bulb)
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
