2.0

Web guiding system EKR 1500 EDV-No.: V3D.010.01.03 Chapter: 2.0

with analogue sensors and CCD 2004 Date: 12.04.2011 Page: 4/4

2.8 CCD 2004

Operating voltage: 15V to 24V (by amplifier)

Power consumption: 6W

Measuring band: 8mm, typical

Min. line width: 0,8mm

Sensor resolution: 2000 pixel

Exposure time: min. 1ms

max. 20ms

Interface: serial interface RS485 for BST eltromat module bus

Protection class: IP54

Ambience conditions: temperature: 0 - 45 deg.C

atmospheric humidity: 5 - 90%, non-condensed

Weight: 845g

2.9 Pneumoelectric transducer ZT 6.008

Power supply: by amplifier

Signal inputs: 0 - 10 mbar

Output: ± 10V

Protection class: IP54

Ambience conditions: temperature: 0 - 45 deg.C

atmospheric humidity: 5 - 90%, non-condensed

Dimensions (standard application): W = 200mm

H = 70mm

L = 120mm (without air connections)
