BST eltromat EKR 1500 User Manual

2.0
Web guiding system EKR 1500 EDV-No.: V3D.010.01.03 Chapter: 2.0
with analogue sensors and CCD 2004 Date: 12.04.2011 Page: 3/4
2.5 Ultrasonic sensor US 2003, US 2008
Power supply: by amplifier
Measuring band: 15mm, typical
Maximum sensing range: 15mm, typical
Output: analogue
Protection class: IP54
Ambience conditions: temperature: 0 - 45 deg.C
atmospheric humidity: 5 - 90%, non-condensed
Dimensions (standard application): W = 25mm
H = 76mm
L = 113mm
2.6 Ultrasonic sensor US 2007
Power supply: by amplifier
Measuring band: 15mm, typical
Maximum sensing range: 15mm, typical
Output: analogue
Protection class: IP54
Ambience conditions: temperature: 0 - 45 deg.C
atmospheric humidity: 5 - 90%, non-condensed
Dimensions (standard application): W = 25mm
H = 94mm
L = 69mm
2.7 Ultrasonic sensor US 2009
US 2009/40
US 2009/70
Power supply:
by amplifier
Measuring band:
12 mm
14 mm
Maximum sensing range:
12 mm
14 mm
Output
analogue
analogue
Protection class:
IP 67
IP 67
Ambience conditions:
temperature: 0 ... +60 °C
atmospheric humidity: 5…90%
temperature: 0 ... +60 °C
atmospheric humidity: 5…90%
Dimensions:
W: 96 mm
H: 88 mm
L: 39 mm
W: 96 mm
H: 118 mm
L: 39 mm
