2.0

Web guiding system EKR 1500 EDV-No.: V3D.010.01.03 Chapter: 2.0

with analogue sensors and CCD 2004 Date: 12.04.2011 Page: 2/4

2.2 Edge sensor IR 2001

Power supply: by amplifier

Measuring band: 12mm, typical

Maximum sensing range: 15mm, typical

Output: analogue

Protection class: IP54

Ambience conditions: temperature: 0 - 45 deg.C

atmospheric humidity: 5 - 90%, non-condensed

Dimensions (standard application): W = 40mm

H = 95mm

L = 107mm

2.3 Edge sensor IR 2002

Power supply: by amplifier

Measuring band: 8mm, typical

Maximum sensing range: 13mm, typical

Output: analogue

Protection class: IP54

Ambience conditions: temperature: 0 - 45 deg.C

atmospheric humidity: 5 - 90%, non-condensed

Dimensions (standard application): W = 25mm

H = 57mm

L = 85,5mm

2.4 Edge sensor IR 2005

Power supply: by amplifier

Measuring band: 12mm, typical

Maximum sensing range: 15mm, typical

Output: analogue

Protection class: IP54

Ambience conditions: temperature: 0 - 45 deg.C

atmospheric humidity: 5 - 90%, non-condensed

Dimensions (standard application): W = 25mm

H = 94mm

L = 69mm
