2.0
Web guiding system EKR 1500 EDV-No.: V3D.010.01.03 Chapter: 2.0
with analogue sensors and CCD 2004 Date: 12.04.2011 Page: 1/4
2. Technical Data
2.1 EKR 1500
* Line voltage: 115V/230V +10% / -20% 50-60Hz
* Power consumption: approx. 80VA
* Fuses: 115V 1 AT
230V 0,5 AT
* Outputs: amplifier (adjustable, see also ‘Lay jumper according to
application’, chapter 5.0, point 5.1)
+/- 24V; max. 1A or
+/- 24V; max 0,33A or
+/- 300mA current source of electric power short circuit proof,
Dither amplitude adjustable
Supply to accessories
+/- 12V (min. +/- 11,4V) at max. 50mA
+ 24V non regulated supply max. 0,4A
Status signal (”system OK”)
potential-free change-over switch, max. 230V, 1A
* Inputs: remote inputs (signification see ”Truth table” chapter 7)
lock-out (controller interlock): possible by means of external
switch or PLC
limit switch inputs: (without cut-out)
R
i
= 4,7 kOhm
active (1) > 8V
not active (0) < 4V
t
low
> 30ms
U
in Max
acc. to IEC 1,2kV / 50µs
analogue inputs (see also chapter 5, point 5.1 and connecting
plan)
2x 0...+ 5V or 0...+ 10V, individual adjustable
2x ± 9,75V or 0... + 9,75V, individual adjustable
2x ± 11,75V
1x NAMUR adaptation with output ± 11,75V
tacho input for motor powered actuator
* Interface: serial interface RS485 for BST eltromat module bus
* Protection class: IP 54
* Ambience conditions: temperature: 0 - max. 45 deg.C
atmospheric humidity: 0 - 90%, non-condensed
* Dimensions: W = 263mm, D = 214mm without screwed connections,
H = 115mm
* Weight: approx. 3kgs
