1.0
Web guiding system EKR 1500 EDV-No.: V3D.010.01.03 Chapter: 1.0
with analogue sensors and CCD 2004 Date: 12.04.2011 Page: 1/5
Please follow the instructions of
Start-up, maintenance and installation
as described in the operating instructions
1. Description
1.1 General
The EKR 1500 system is a microprocessor-controlled web guiding system. This guiding system
may be used for:
- web edge guiding (right or left)
- center-line guiding
- guiding on continuos or interrupted printed lines
- guiding on continuos or interrupted printed edges
- guiding to a printed line or edge with automatic change-over to edge or center-line
guiding when the printed line/edge is interrupted or has got lost (for example, in the
case of a web splice)
Please contact the producer for any different application.
The system has PLC-compatible inputs and also an ‘OK-relay’ with NO and NC contact.
Full integration into the machine control system via:
- I-O Module potential-free in- and outputs for extended PLC messages and
commands
- Intercon-Module direct, serial connection for integration of system results,
messages and commands into the machine control system.
- Interbus-S Module direct connection to Interbus-S Module as remote bus station
- PDP-Module for instantaneous communication with locally peripheral
equipment
Notice: Please find the connection plans of the nominated modules at the corresponding
operating instructions.
1.2 Connectable components
The following components have been discontinued. They are no longer available for new systems.
The corresponding sections of the operating instructions are only relevant to the operation of
existing systems.
IR 2001/10/30 resp. IR 2005/3/30
US 2007/40 resp. US 2009/40
Profibus DP-Module for switching cabinet installation
