Web guiding system EKR 1500 EDV-No.: V3D.010.01.03 Chapter: 1.0
with analogue sensors and CCD 2004 Date: 12.04.2011 Page: 2/5
1.3 Operating elements
* The amplifier includes all necessary operating elements.
Option: - Remote control by external signals, sensors or keys
Attention! External keys will interlock the reverse function keys at the amplifier.
- If system locking is desired (e. g., in case of machine stop), this can be
achieved by means of external contacts or signals from the PLC.
* Connection of components via separated terminal compartment.
Advantage: quick and easy accessibility to the terminal parts.
* Indication of web edge position by two LED arrays
Advantage: - simple control of the web edge within the measuring range of sensors
- simple adjustment of the desired position of the web or edge sensors
- variations of web width exceeding via the admissible value
