25
BT Decor 310 ~ Issue 2 ~ 1st Edition ~ 27th August ’03 ~ 5598
Wall mounting
1. Locate lugs and mount into holes
under base unit as shown.
2. Swing mount down to clip into
top hole.
3. Drill 2 holes, 25mm deep using a
3mm drill, for the screws using the
template. Ensure that you do not drill
into any hidden wiring or pipes. Insert
the wall plugs provided and then
insert a screw into each hole. Leave
2-3mm between
the head of the screw and the wall.
4. Position the product onto the screws.
5. Drop down to secure.
Handset hook
Keeps the handset in place when the
BT Decor 310 is wall mounted.
Revolve the handset catch on the base
unit. The handset will now be able to
rest on the hook when wall-mounted.
4
5
1
2
