BTM SPIN BIKE - Hardware Parts List

4
10. Monitor x 1 11. Monitor Holder x 1 12. Lock Knob M1 x 2
13. Lock Nut N1 x 1 14. Bolt S1 x 4 15. Allen Bolt T1 x 4
16. Nut x 4 17. Washer x 8 18. Allen Wrench x1 19. Open End Wrench x 2
PARTS LIST
NO. ITEM QTY NO. ITEM QTY
1
Main Body
1
10
Monitor
1
2
Rear Stabilizer
1
11
Monitor Holder
1
3
Front Stabilizer
1
12
Lock Knob M1
2
4
Saddle
1
13
Lock Nut N1
1
5
Saddle Adjustment Frame
1
14
Bolt S1
4
6
Saddle Post Assembly
1
15
Allen Bolt T1
4
7
Handle Frame
1
16
Nut
4
8
Handle Post Assembly
1
17
Washer
8
9
Pedal (L/R) Set
1
HARDWARE PARTS LIST
NO. ITEM QTY NO. ITEM QTY
18
Allen Wrench
1
19
Open End Wrench
2
